1080P AHD Remote Control Car Bus RV 3G 4G GPS Mobile HD 4CH DVR Video Recorder
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW9034BGS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 50,000pcs per month; |
|
Detail Information |
|||
| Product Name:: | 4G 5G Wireless MDVR GPS With Universal Tpms Tire Pressure Monitoring System | Special Features: | Display Rotate,sd/mmc Card,Bult In GPS,Real Time Surveillance,wifi Function,Parking Monitor,Speed And Coordinates Recording |
|---|---|---|---|
| Software: | CMSV6 | Power Input: | 12V-36V |
| Customize: | Support | Video Formatv: | PAL Or NTSC |
| Video Compression: | H.264 | Channel: | 4 Channel |
| Camera Input Resolution: | AHD1080P/720P/CVBS | Preview: | Support Single Channel And 4 Channelpreview |
| Storage Media: | Dual SD, Max 512GB | Menu Language: | Chinese、English、other（can Be Customized） |
| Highlight: | 1080P Mobile DVR,4CH Mobile DVR,3G Mobile DVR |
||
Product Description
1080P AHD Remote Control Car Bus RV 3G 4G GPS Mobile HD 4CH DVR Video Recorder
Please note:
This link is MDVR only (GPS,WIFI,4G function optional).
This link does not include cameras and monitors. If you have a need for cameras and monitors or other accessories, you can contact sales.
Your inquiry is welcome.
This 1080P AHD 4CH DVR video recorder is tailor - made for diverse mobile scenarios, including remote - control cars, buses, and RVs.
Equipped with 1080P AHD technology, it delivers crystal - clear footage, capturing every detail. The four - channel design enables multi - angle recording simultaneously, eliminating blind spots. Thanks to 3G/4G connectivity, real - time video can be transmitted to your mobile device. Paired with GPS, it logs driving routes, too.
Highly versatile, it meets the recording needs of remote - control car enthusiasts. It’s also a great aid for fleet management, enhancing driving safety. Undoubtedly, it’s an essential video - recording device for mobile travel.
| Item | specification | |||
| OS | Linux | |||
| Language | Chinese/English/Russian/Others (can be customized) | |||
| Video Compression | H.265 H.264 | |||
| OSD | Character overlay function,Overlays information such as date time and vehicle ID | |||
| GUI | Graphical User Interface | System parameters can be set through an external display screen and remote control operation | ||
| Video Record System | Video Input |
4CH:1080P,720P,D1 8CH:1080P,720P,D1 |
||
| Video Output | 1 composite video output+optional VGA output, 1.0Vp-p, 75 Ω, supports 1 full screen and 2/4 split channels | |||
| Preview | support Single channel, 2/4 screen splicing preview, support manual/event triggered full screen display function | |||
| Resolution | Maximum support: 4*1080P 25 frames per channel; 8*1080P 15 frames per channel. | |||
| Video Quality | 0-8 levels video recording available, 0 is the best level, 8 is the lowest level. | |||
| Video Standard |
PAL: 100 frames per second, CCIR625 line, 50 fields NTSC: 120 frames per second, CCIR525 line, 60 fields; CIF: 256Kbps ~ 1.5Mbps, multi levels video quality optional; HD1: 600Kbps ~ 2.5Mbps, multi levels video quality optional; D1: 800Kbps ~ 3Mbps, multi levels video quality optional; 720P : 1Mbps~2Mbps, multi levels video quality optional; 1080P: 1Mbps~4Mbps, multi levels video quality optional; |
|||
| Record Mode | Default automatic recording, supporting ignition recording, manual recording, alarm recording, etc | |||
| Audio | Audio Input | 4 or 8 channel aviation Plug | ||
| Audio Output | 1channel | |||
| Compression | G.711A compression, 8KB/s speed | |||
| Alarm Input | 4CH IO Alarm Input, pulse speed input,support alarm linkage function | |||
| Alarm Output | 2-channel switch output, linked with sound and light alarm, oil and power outage, etc | |||
| Communication Interface | 1CH RS232,Expandable POS machine, fuel sensor, LED advertising screen, OBD, etc | |||
| 1CH 485 interface, can connect PTZ,etc. | ||||
| Wireless transfer | Built-in 4G network wireless transmission, TD-LTE, FDD-LTE | |||
| Position | Support built-in GPS/BD module, can report to the CMSV7 standard platform | |||
| SD card | SD card | Support Two SD cards ,a maximum of 512G for a single card, can support simultaneous video streaming to ensure data security | ||
| Update Mode | Support USB flash drive upgrade, SD card upgrade, FTP remote automatic upgrade | |||
| Storage Mode | Exclusive bare disk storage method: Currently it is a relatively advanced storage method in the industry | |||
| USB | Front USB interface, can use USB flash disk to upgrade and backup ; support USB mouse to backup video | |||
| Video Playback | Video Search | Search video by Record Time/Record Mode etc | ||
| Playback | Supports a maximum of four channels simultaneous replays, including pause, fast forward, and fast rewind | |||
| Support x 2,x4,x8,x16. fast forward or fast backward play | ||||
| Voltage &Power Consumption | Power Management |
Adaptive wide power input, with protection functions such as overload, undervoltage, short circuit, and reverse connection; Support timed power on/off and delayed shutdown functions. |
||
| Voltage Input | DC:+12V ~ +36V | |||
| Voltage Output | +12V@2.5A,+5V@2A | |||
| Power Consumption | Normal Working ＜5W | |||
| Working Environment | Temperature | -20℃ to +70℃ | ||
| Humidity | 20% to 80% | |||
| Safety Management | Password Access | Two level management of user password and administrator password | ||
| others | Size | 15CM (D)* 14.7CM(W)* 4CM(H) | ||
| Net Weight | 0.7 Kg | |||
DVR Video Recorder Platform sreenshots
