Advanced 2K 4G SIM Card Dual Lens GPS Dash Camera Night Vision WDR Loop Recording Functions Compatible Smart VW Cars Android IPS
Product Details:
| Place of Origin: | Guangdong,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-Z-A19 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 5,000pcs per month |
|
Detail Information |
|||
| Master Chip: | Quanzhi V853 | Image Sensor: | GC4653 Sensor |
|---|---|---|---|
| ROM: | NOR Flash 128Mb | RAM: | 256MB |
| Display: | 3.0 Inch | Shot: | F/NO 1.60 FOV(D)136 FOV(H)115 FOV(V)61 |
| Screen Mode: | Positive Image Display And Positive Image Video Playback | Wireless Communication WIFI: | Built In 2.4GHz Hotspot WiFi |
Product Description
Advanced 2K 4G SIM Card Dual Lens GPS Dash Camera Night Vision WDR Loop Recording Functions Compatible Smart VW Cars Android IPS
The dashcam is a ultra high definition 2K & 1080P dual lens 3.0 inch non-touch screen vehicles dash camera with 4G & WiFi,supports GPS & Beidou 2 bands tracking with external antenna,loop recording,G-sensor,24h parking monitoring and real-time video viewing on APP.
Product Features
1. 4G/WiFi/Hotspot: user can use some programs or APPs with 4G or WiFi connected after inserting 4G SIM card,such as Google Map,etc.
2. Remote monitoring: support user monitor or view real-time video through Phone App(CarKeeper),dash cam transfers the real-time to the APP and user can view live video or playback view the previous vides.
3. GPS tracking: camera supports monitoring and alarm, gps trackign history checking and one key share cartife. Car driving path will be recorded and real-time payback on Carkeeper,and share your trip logger or interesting videos with your friends,check pitures and videos from your friends too.
4. Parking monitoring: supports front and back camera shooting when parking,camer can automatically turn on and start recording when detects any impact or collision with recording few seconds to make sure 24hours parking guard if someone is close to the car.
1. 4G/WiFi/Hotspot: user can use some programs or APPs with 4G or WiFi connected after inserting 4G SIM card,such as Google Map,etc.
2. Remote monitoring: support user monitor or view real-time video through Phone App(CarKeeper),dash cam transfers the real-time to the APP and user can view live video or playback view the previous vides.
3. GPS tracking: camera supports monitoring and alarm, gps trackign history checking and one key share cartife. Car driving path will be recorded and real-time payback on Carkeeper,and share your trip logger or interesting videos with your friends,check pitures and videos from your friends too.
4. Parking monitoring: supports front and back camera shooting when parking,camer can automatically turn on and start recording when detects any impact or collision with recording few seconds to make sure 24hours parking guard if someone is close to the car.
AHD driving recorder product parameters:
| 4G Driving Recorder Parameters | |||
| Product Name | 2K+post recording AHD | ||
| Model | VW-Z-A19 | ||
| Application | It is a Linux system car recorder motherboard that integrates functions such as front 2K rear AHD, one click capture, parking monitoring, remote live streaming, WiFi LAN preview, real-time positioning, trajectory playback, low battery protection, and ultra-low power consumption. | ||
| Product specifications | Master Chip | Quanzhi V853 | |
| Image Sensor | GC4653 Sensor | ||
| ROM | NOR Flash 128Mb | ||
| RAM | 256MB | ||
| Display | 3.0 inch | ||
| WIFI | RTL8189 | ||
| Shot | F/NO 1.60 FOV(D)136 FOV(H)115 FOV(V)61 | ||
| Positioning | Global Positioning System (GPS), Beidou dual-mode GPS+BDS | ||
| Function | Recording format | The video encoding is H.264, H.265, and the file format MP4 supports custom defined TS format | |
| Operating System | Linux | ||
| Record Mode | Automatic recording upon power on | ||
| Video recording duration selection | Close, 1 minute, 2 minutes, 3 minutes, 5 minutes, 10 minutes | ||
| Video resolution | First 2K P30 2560 * 1440 | ||
| Rear 720P P25 1280 * 720 | |||
| Screen mode | Positive image display and positive image video playback | ||
| Video | TS format | ||
| 4G: 2/3/4G communication | Supported frequency bands: B1, B3,B5,B8,B38,B39,B40,B41 | ||
| Wireless communication WIFI | Built in 2.4GHz hotspot WiFi | ||
| Display screen operation | Turn off for 1 minute, 3 minutes, 5 minutes, and 10 minutes | ||
| Photo format | JPG. | ||
| 5376*4032 (16M) | |||
| 4032×3024 (12M) | |||
| 3648×2736 (10M) | |||
| 3264×2448 (8M) | |||
| Image effect settings | Exposure compensation, white balance | ||
| G-Sensor function | G-Sensor vibration triggers automatic power on recording, locks encrypted files for saving, and automatically shuts down | ||
| Start event recording and save the current file based on the duration of the recording file | |||
| The file saved under the G-Sensor event will not be deleted | |||
| Display | Normal image output | ||
| File store | External TF card storage, supporting up to 256GB TF card storage | ||
| Video or photo file time watermark information can be optionally turned on/off | |||
| Output | ///// | ||
| High definition screen with high resolution audio and video output | |||
| Speaker | Built-in speaker | ||
| Microphone | Built in microphone recording | ||
| Power outage delay shutdown | Default 10S | ||
| Power supply | External car mounted DC5V-DC12V (auto start triggers recorder to automatically start recording, auto stop triggers recorder to stop recording and shut down) | ||
| SD card holder | Mini TF Card | ||
| Indicate status | Pilot lamp | Red and blue indicator lights, indicating power and network status | |
| Power on/off logo | Customers can customize themselves | ||
| Power port | working voltage | Power supply: DC5V | |
| quiescent current | 200uA | ||
| operation temperature | operation temperature | -20℃－－+70℃ | |
| storage temperature | storage temperature | -30℃－－+85℃ | |
Mini dash cam FQA:
1. Do you provide the free CMS?
Yes, is free of charge. We will provide you the authorized code after you buy our equipment.
2. Which OS can run this software?
server2002 / server2008 / Windows xp / Windows 7 / Windows 10, both 32bit and 64bit.
3. After we build our own server, can the IP of units be changed remotely?
Actually we can provide the protocol package for you to develop your own CMS. You could remotely change the settings of your vehicles, this is no problem.
Any further questions, please don't hesitate to contact us, we are very pleased to help you.
