6CH IPC NVR 4G GPS 6 Channel Network MNVR for Mining Gold River Sand Pumping Boat Jet Suction Dredger
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW9046 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 5,0000 pcs per month |
|
Detail Information |
|||
| Product Name: | 6 Channel Network MNVR | Alarm Input: | 4CH IO Alarm Input, Pulse Speed Input,support Alarm Linkage Function |
|---|---|---|---|
| Compression: | G.711A Compression, 8KB/s Speed | Audio Input: | 4 Channel Aviation Plug |
| Audio Output: | 1channel | Video Input: | 4CH：1080P、720P、D1 |
| Voltage Input: | DC:+12V ~ +36V | Humidity: | 20% To 80% |
| Temperature: | -20℃ To +70℃ | ||
Product Description
6CH IPC NVR 4G GPS 6 Channel Network MNVR for Mining Gold River Sand Pumping Boat Jet Suction Dredger
Mobile Network Video Recorder (MNVR)
What it is:
A device that records video from digital (IP) cameras mounted in mobile environments like buses, trucks, and rail cars.
How it works:
It uses Ethernet cables (often with Power over Ethernet, or PoE) to connect to and power IP cameras, similar to a standard NVR but designed for mobile, shock-resistant environments.
Key features:
Includes features like GPS positioning, automatic monitoring, geo-fencing, data storage (on HDD/SSD/SD cards), and remote access via 4G or Wi-Fi.
Applications:
Used in public transportation, school buses, and other commercial fleets for security and operational monitoring.
What is the difference between MDVR and MNVR?
The main difference is that a MDVR (Mobile Digital Video Recorder) records analog (coaxial) cameras, while an MNVR (Mobile Network Video Recorder) records IP (network) cameras. This means MDVRs use coaxial cables and are designed for older analog systems, whereas MNVRs use Ethernet cables and are designed for modern IP cameras.
Here's a breakdown of the key distinctions:
MDVR (Mobile Digital Video Recorder)
• Camera Type: Records from analog cameras.
• Cabling: Connects to cameras via coaxial cables.
• Image Quality: Generally offers lower resolution and image quality compared to MNVR systems.
• Cost: Often less expensive than MNVR systems.
• Use Case: Suitable for situations with existing analog cameras or when a lower-cost solution is needed.
MNVR (Mobile Network Video Recorder)
• Camera Type: Records from IP cameras.
• Cabling: Connects to cameras via Ethernet cables (RJ45 ports).
• Image Quality: Provides higher resolution and greater clarity.
• Technology: A more modern and advanced technology.
• Use Case: Ideal for systems requiring higher quality graphics, network connectivity, and simpler installation.
Choosing Between Them
• Choose MDVR: if you have existing analog cameras or need a more budget-friendly option.
• Choose MNVR: if you require higher image quality, the benefits of IP cameras, or want a more modern and advanced surveillance system.
Specification
| OS | Linux | |||
| Language | Chinese/English/Others (can be customized) | |||
| Video Compression | H.264/H.265 | |||
| OSD | Overlays information such as date time and vehicle ID | |||
| GUI | Graphical User Interface | Can connect to external LED screen. Setup system parameters with the remote control. | ||
| Video Record System | Video Input | 6CH:1080P,720P | ||
| Video Output | 1 CVBS video AV, 1 VGA, 1 Aviation joints | |||
| Preview | Multi-mode screen preview, support manual/event trigger full-screen display function | |||
| Resolution | Max support: 8*1080P | |||
| Video Quality | Adjustable video levels from 1 to 8: best level 1, minimum level 8 | |||
| Video Standard | Default automatic recording, support ignition recording, manual recording, alarm recording, etc | |||
| Audio | Audio Input | 6CH | ||
| Audio Output | 1CH | |||
| Compression | G.711A compression, 8KB/s speed | |||
| Alarm Input | 4 CH of IO alarm input; It has the function of alarm linkage | |||
| Alarm Output | 2CH output, linkage sound and light alarm, oil and power cut-off, etc | |||
| Communication Interface | 1CH RS232, can be connected to oil sensor, temperature sensor, OBD, etc | |||
| 1CH RS485 (extensible) | ||||
| Wireless transfer | Support 4G, TDD-LTE, FDD-LTE etc | |||
| Position | Built-in GPS/BD module | |||
| Storage | storage | SD Card Max 512GB ,HDD or SSD HDD Max 2TB. | ||
| Upgrade | Support USB flash disk updating SD card upgrade , OTA remote upgrade automatically | |||
| USB | Front panel supports USB port, support USB flash disk upgrade to backup; hard disk box USB port, can back up video data | |||
| Video Playback | Video Search | Search video by Record Time/Record Type etc | ||
| Playback | Max support 8CH Replay /Stop/Fast Forward/Fast Reverse at same time | |||
| Support x 2,x4,x8,x16. fast forward or fast backward play | ||||
| Voltage &Power Consumption | Power Management | Adaptive wide power input, support Wide Voltage, Over-load,Over-voltage,Short Circuit,Reverse Protection..Support Time Setting/Delay power off | ||
| Voltage Input | DC:+12V ~ +36V | |||
| Voltage Output | +12V@1A | |||
| Power Consumption | Normal Working ＜5W | |||
| Working Environment | Temperature | -10℃ to +70℃ | ||
| Humidity | 8% to 90% | |||
| Safety Management | Safety enter | user/Admin 2 Levels Different Passwords , | ||
| CMS access | CMSV6, JT/T808-2011, JT/T808-2019, JT/T1078-2016 | |||
| Size | 18.5CM (L)* 16.8CM(W)* 6.2CM(H) | |||
| weight | 2 Kg | |||
1.Q: Does the MDVR support Hard drive and SD card?
A: Yes, HDD version MDVR supports SSD, HDD, and SD card. SD card version MDVR supports max 2 SD card.
The storage capacity can be from 32GB to 2TB.
2.Q: Is it difficult to install MDVR into the vehicle?
A: Actually it is easy to install it into vehicle. Most driver can figure out how to connect the power cables.
And the camera installation is more easy. Just screw, connect and mount on the target place inside the vehicle.
3.Q: If I need door open and close alarm, overspeed alarm, reverse video, brake video, left-turn video, right-turn video, etc,
is it available?
A: Definitely yes!
The I/O RS232 and 485 extension port is for all expanded purposes, including the functions above.
In fact, there are more customized functions which can be connect through this port, such as Fuel sensor, Counter system,
PTZ camera, and so on.
4.Q: We have our own platform and server, can we use your MDVR? Do you have SDK or can you do customized platform for us?
A: Yes, we have SDK ready and welcome your OEM customized order!
