| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-108A |
| Minimum Order Quantity: | 5pcs |
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default; |
| Delivery Time: | 2-3 days for samples, 5-10 days for large orders |
| Payment Terms: | Western Union, T/T, Paypal |
| Supply Ability: | 5,000pcs per month; IR LED Color Camera 1/3" Mini Hidden Camera for 360 Degree Cameras System |
| Type: | Taxi Camera | Sensor: | Sony CCD/720P |
|---|---|---|---|
| TV System: | PAL Or NTSC | Voltage: | DC12 |
| Connector: | 4 Pin Aviation, Square, BNC Connector | Resolution: | CCD 600TVL/ 720P AHD |
| View Angle: | 170 Degree | Application: | Taxi, Small Car, Bus, Van |
| IR Lights: | 4 Pcs | Lens: | 1.8mm/2.2mm |
| High Light: | small hidden cameras,security monitor camera |
||
IR LED Color Camera 1/3" Mini Hidden Camera for 360 Degree Cameras System
Main Specifications
|
Feature
|
Universal car vehicle
|
|
Image Type
|
1/3" 1/4 Color CCD/CMOS
|
|
Night vision
|
With IR lamp
|
|
LED
|
4pcs
|
|
TV System
|
NTSC/PAL
|
|
Lens Angle (Deg.)
|
150 degree
|
|
IP Rating
|
IP69K
|
|
Connector
|
4P connector or RCA connector for selection
|
|
Effective Pixels
|
648*512 /640*480
|
|
Horizontal Resolution
|
420TVL/600TVL
|
|
B.L.C
|
Back light Compensation (Auto)
|
|
White Balance
|
Auto White Balance (Auto)
|
|
Minimum Illumination
|
0Lux (LED ON)
|
|
S/N Ratio
|
≥48dB
|
|
Electronic Shutter
|
1/60~1/100,000 Sec
|
|
Power consumption
|
<3W
|
|
Built-in Lens
|
f:1.8mm
|
|
Power Consumption
|
DC 5-20V
|
|
Audio
|
without
|
|
Operation Temperature
|
-30℃~+70℃.RH95% Max
|
|
Storage Temperature
|
-40℃~+80℃.RH95% Max
|
|
Certificate
|
FCC,CE,ISO9001,IATF16949, RoHs
|
|
Weight/Package
|
4Pin connection diagram:1.2KG
|
Application:
1. Taxi or small car, bus
2. MDVR or rearview camera system
