1080P AHD 700TVL 0.01Lux Side View Surveillance Camera 70mA

Basic Information
Place of Origin: Shenzhen, China
Brand Name: Vanwin Tracking
Certification: CE/FCC/RoHS
Model Number: VW-208
Minimum Order Quantity: 5 pcs
Price: negotiated
Packaging Details: Neutral giftbox, with foam plastic bag packed, customize brand is available when order reach 100pcs
Delivery Time: 2-3 days for samples, 5-10 days for large orders
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 5,000pcs per month
Type: Side View Camera Resolution: 720P/960P/1080P
Power: DC12 Or 24V TV System: PAL Or NTSC
Camera Lens: 2.1MM/2.8MM/3.6MM Feature: Waterproof, Dustproof
Color: Housing Black Angle Lens: Can Be Adjusted
Viewing Angle: 120 Degree Service: OEM/ODM
High Light:

0.01Lux Side View Surveillance Camera

,

700TVL Side View Surveillance Camera

,

70mA Cctv Surveillance Camera

Private Mold 1080P AHD Side View Camera for Surveillance with Good Night Vision





The Side View camera is used with Mobile DVR / Car DVR (with 3G, 4G, GPS,WiFi) or Car Monitor for vehicle real time monitoring and safe driving, applied with car cameras used for vehicle monitoring in bus, taxi, school, bus, truck, police car, tour bus, tanker truck, escort car etc.



Main Features:

  1. Side View Camera for Heavy-duty or Bus
  2. Analog 600TVL/700TVL/800TVL or AHD 720P/960P/1080P for options
  3. 10 PCS Infrared LED lights
  4. CE,FCC,RoHS Certificates
  5. Private Mold
  6. Angle can be adjusted
  7. Wide horizontal angle degree



Technical Specification



Image Sensor 1/3" 600TVL SONY CCD 1/3 700TVL SONY CCD
Video System PAL/NTSC PAL/NTSC
Pixels PAL:752(H)×582(V) PAL:976(H)×582(V)
NTSC:768(H)×494(V) NTSC:976(H)×494(V)
Horizontal Resolution 600 TVL 700 TVL
Min Illumination 0.01LUX(0 Lux IR on) 0.01Lux (0 Lux IR on)
SNR ≥46dB ≥48dB
Electronic Shutter 1/50-1/10000(S) 1/50(1/60) - 1/100000 (S)
Video Output 1.0V±0.5Vp-p 75Ω 1.0V±0.5Vp-p 75Ω
View Angle 120° 120°
Working Voltage DC12V±0.5V DC12V±0.5V
Consumption 100mA±10% 70mA±10%
Display image Mirror/normal optional Mirror/normal optional
MIC Optional optional



Installation Cases

1080P AHD 700TVL 0.01Lux Side View Surveillance Camera 70mA 0

1080P AHD 700TVL 0.01Lux Side View Surveillance Camera 70mA 1
