3.6mm Megapixel 0.5Lux IP69 IP Vehicle Camera For Back / Front View

3.6mm Megapixel 0.5Lux IP69 IP Vehicle Camera For Back / Front View

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Vanwin Tracking
Certification: CE/FCC/RoHS
Model Number: VW-388

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: negotiated
Packaging Details: Neutral giftbox, with foam plastic bag packed, customize brand is available when order reach 100pcs
Delivery Time: 2-3 days for samples, 5-10 days for large orders
Payment Terms: Western Union, T/T, Paypal
Supply Ability: 5,000pcs per month; Universal Mount Infrared Adjustable Angle Rear View Back Up Camera with Anti-Glare Shield
Get Best Price Contact Now

Detail Information

Type: Back Up Camera TV System: PAL Or NTSC
IR Lights: 18pcs IR Cut: YES
POE: Support Material: Metal Housing
Power Supply: DC12V, 0.3A Test Time: Over 48 Hours
Resolution: 720P/960P/1080P Optional Chip Mode: AHD Camera Or Analog Camera Or IP
High Light:

3.6mm Megapixel IP Vehicle Camera


IP69 IP Vehicle Camera


0.5Lux Cctv Surveillance Camera

Product Description

DC 12v power supply Infrared IP69 IP Car Vehicle Camera for Back / Front View


Camera Specification

Main Stream HD 1920*1080P 1-25fps
Megapixel Lens 2.8mm/3.6mm
IR LED & Visible Range IR LED 18pcs Φ5mm (850nm/60°), Max.10-15m
Day & Night System Mechanical ICR
Min. Illumination 0.5Lux(Color) / 0 Lux IR On
Brightness Auto/Manual
Mirror Yes
Heatbeat Message Yes
Compression H.264/MJPEG
Code Stream 128Kbps~8Mbps, VBR/CBR
Audio N/A
LAN Interface Ethernet 10/100 base-T, RJ45 x1
Support P.o.E POE: 802.3a/f , Transmission distance <100m (Optional)
After Event Process Upload JPEG via FTP, Email or specified alarm center
ONVIF Standard Access ONVIF V2.0/V.2.2/V.2.3/V2.4
Motion Detection Yes, Support Multiple Setting Areas
System Upgrade Yes, Firmware upgrade
PTZ Control Not Applicable for Fixed Cameras
Power DC12V, 0.3A
Dimension 75mm x 40mm x 80mm
Weight 0.4kg

Our Advantages


1. 720P/960P/1080P AHD Camera for optional ,also analog chips like CMOS/CCD to choose

2. We also have our own SMT chip factory ,who provides all kinds of chips and mainboard for cameras and MDVR suppliers.

3. We can give you best price as we can ,and also very good quality products.

4. Please trust on us that many clients have ordered over 100 sets after samples testing .

5. We provide of all kinds of cameras and monitors for choice .


Welcome you to test strictly .
