2.0MP NTSC Dc 12v 600TVL Waterproof Dome Cameras Night Vision
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-205 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral giftbox, with foam plastic bag packed, customize brand is available when order reach 100pcs |
| Delivery Time: | 2-3 days for samples, 5-10 days for large orders |
| Payment Terms: | Western Union, T/T, Paypal |
| Supply Ability: | 5,000pcs per month , |
|
Detail Information |
|||
| Type: | Mini Dome Cameras | Resolution: | 600TVL, 720P/960P/1080P |
|---|---|---|---|
| Lens Angle: | 90/105 Horizontal Degree | Lens: | 2.1mm / 2.8mm /3.6mm |
| TV System: | PAL Or NTSC | Sensor: | CMOS / CCD |
| Power: | 12V- 24V | IR LED: | 12pcs |
| Audio Built-in: | Support | Waterproof: | Yes |
| Night Vision: | Support | Warranty: | 12 Months |
| High Light: | 600TVL Waterproof Dome Cameras,2.0MP Waterproof Dome Cameras,NTSC Night Vision Dome Cameras |
||
Product Description
Starlight night vision Waterproof 1080P mini dome cameras with power supply dc 12v
Overview
- This is 1080P AHD Mini dome cameras with starlight night vision for internal use.
- It works with 12pcs F5 infrared LEDs to create 15 meters infrared distance for night vision to monitor in dark environment.
- It adopts 2.1mm, 2.8mm, 3.6mm fixed focus lens to let you view objects within 10~15 meters.
- It can be worked with DVR recorder, quad processor, DVR, Reversing system. It can be viewed through monitor, TV, PC, smart phone and etc.
Camera Technical Specifications
| Type | HD 2.0Megapixel |
| Image Sensor | 1/2.7" progressive scan CMOS |
| Horizontal Resolution | 2.0Megapixel |
| TV system | PAL/NTSC |
| Effective pixels | 1920(H)*1080(V) |
| Minimum Illumination | 0.01Lux@(F1.2,AGC ON),0 Lux with IR |
| S/N | ≥41dB |
| Day and night switch | Auto(ICR) |
| Auto Gain Control | Support |
| Back light compensation | Support |
| White Balance | Auto / Manual |
| Digital Noise Reduction | Adaptive digital noise reduction, 2D/3D-DNR |
| Electronic Shutter | AUTO/1/50(1/60)-1(50,000Sec) |
| Video Output | Follow AHD / TVI / CVI / CVBS standard (4 in 1 output) |
| AUDIO | Support |
| OSD menu | UTC function |
| Lens | 1.56mm megapixel lens,M12*P0.5 |
| Visual Angle | Ceiling mounted :360°,Wall mounted: 180° |
| IR LEDS Quantity | 23 PCS ￠5 LEDS |
| IR distance | 10～15 meters |
| Operating Temperature/Humidity | -30°C~+70°C/Humidity≤90%(No condensation) |
| Power Supply | DC12V±10% |
| Power Consumption | ≤3.6W |
| Dimension | Ф150*46(mm) |
There are three kinds pof connectors for option
1. 4-pin connector
2. RAC connector
3. BNC connector
FQA
Q: What is the MOQ ?
A: 1 peice
Q: How fast for sample delivery?
A: 3-7 days
Q: Can I get a lower price if I order large quantities?
A: Yes, the larger the quantity, the cheaper the prices.
Q: How about the warranty period?
A: One year!
Q: How can you guarantee the quality?
A: We have a QC team with 12 years’ experience. All of the products will run through over 4 times’ 100% testing before being delivered.
Want to Know more details about this product
