6CH Alarm Auto 3G Mobile DVR With GPS Track For Fleet Real Time
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW619HD-GSW |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 5,000pcs per month; Auto 3G DVR Mobile Wifi GPS with Camera for Fleet Real time MDVR |
|
Detail Information |
|||
| Power Supply: | 8V-36V | Storage Capacity: | 1TB HDD And 64G SD Card |
|---|---|---|---|
| Functions: | 3G , GPS Track , Wi-Fi ,G-sensor,6CH Alarm Inpu,Lan Port | Software Support: | Client,Server,Playback Software |
| OEM/ODM: | YES Or Customize | H.264 Format: | YES |
| RS232/RJ45 Port: | Support | ||
| High Light: | 6CH 3G Mobile DVR,Alarm Auto 3G Mobile DVR,Real Time 1080p mobile dvr |
||
Product Description
6CH Alarm Auto 3G Mobile DVR With GPS Track For Fleet Real Time
Main Features
1) 4 channel*720P or 1080P for optional
2) H.264 compression format
3) 64GB SD Card
4) 2.5“ SATA 1TB Hard disk
5) GPS tracking
6) 3G remote control
7) Built-in WIFI
8) 6 alarm input, 1 alarm output
9) 2 way intercom
10) Remote oil&power cut-off
11) Mirror recording in SD card
12) Patent UPS continuously working to protect data upon sudden power-off
13) Customized GPS data format sending(optional)
14) Built-in Heater(optional)
15) Lockable, metal HDD handle, protect HDD efficiently
16) Watermark and Time/Date stamp in exported images
Specification
|
Item |
Description |
||
|
OS |
Linux |
||
|
Graphics Operation Interface |
System parameters can be set through external display and remote controller |
||
|
Security Management |
2-level management for user password, administrator password, supporting encrypted transmission |
||
|
Video and Preview |
Video Input, Output |
4-channel video input, 1channel video output; 1.0Vp-p, 75Ω |
|
|
OSD |
Character superposition function, information superposition of time and date, device ID and GPS, etc. |
||
|
Video Compression Format |
Compression coding. Applying hisilicon hi-performance processor. |
||
|
Dual-Stream |
Supported |
||
|
Preview Function |
Preview of 1-channel, 4-image stitching, supporting full screen triggered by event and switching of stitched images |
||
|
Frame Rate |
PAL: 100 frames/s, up to 25 frames/s per channel; NTSC: 120 frames/s, up to 30 frames/s per channel |
||
|
Resolution |
CIF, HD1, D1, 720Pfor selection, support 4*720P recording |
||
|
Quality |
Grade 1 to grade 5 for selection (descending) |
||
|
Bit Rate |
CIF: 256Kbps ~ 1.5 Mbps, 8-level bit rates for selection HD1: 600Kbps ~ 2 Mbps, 8-level bit rates for selection D1: 800Kbps ~ 3Mbps, 8-level bit rates for selection |
||
|
Audio |
Audio Input, Output |
4-channel input, 1-channel output |
|
|
Compression Format |
G.726 coding |
||
|
Recording |
Storage Medium |
Supporting one 2.5” hard drive and one SD card, which supports up to 32G, supporting data redundancy storage technology; |
|
|
File Format/ System |
ASF/FAT32 |
||
|
Video Strategies |
Recording at startup by default, supporting timed recording, recording triggered by alarm and event, as well as manual recording |
||
|
Video Search |
Searching by time, type, storage device and other conditions |
||
|
Video Playback |
Supporting playback on local device, supporting synchronous playback of up to 4 channels and analysis on vehicle information in the files |
||
|
Supporting fast forward, fast backward, play and pause, supporting fast forward and fast backward at 2x, 4x, 8x and 16x speed, supporting file play from selected time |
|||
|
|
|||
| larm | Alarm Input/ Output | 6-channel on/off signal alarm input, 1-channel on/off signal alarm output | |
| Alarm Recording | Prerecording function 15 seconds before alarm, duration of recording after alarm can be adjusted from 30s ~ 30min | ||
| Storage Space Alarm | Supporting settings for alarm of storage space | ||
| Function Alarm | GPS overspeed alarm, acceleration alarm, motion detection alarm | ||
| Communication Ports | RS232, RJ45 10M/100M self-adaptable network interface | ||
| Wireless Transmission (Optional) | Supporting Wi-Fi; | ||
| GPS (Optional) | Supporting external GPS | ||
| PTZ Control | Supporting PTZ control realized by local; | ||
| Parameter Configuration | Supporting parameter configuration functions for mobile DVR coding channel; | ||
| G-Sensor | Embedded | ||
| System Upgrading | Supporting SD card, hard drive upgrading and remote upgrading | ||
| Power Supply and Power Consumption | Power Supply |
1. ACC on/off 2. Hard drive lock on/off 3. Delayed shutdown 4. Timed on/off |
|
| Input Voltage | DC:+8V ~ +36V | ||
| Output Voltage | +12V@4*0.5A; +5V@0.5A | ||
| Power-off Protection | With patented UPS power supply continuous working technology, it can work for 3~5 seconds after external power supply is cut so that the intactness of video data can be kept upon sudden power failure | ||
| Power Consumption | <10W in normal operation; <0.5W in standby mode | ||
| Operating Environment | Temperature | Normal: 0℃ ~ +60℃; upon hard drive preheating: -25℃ ~ +60℃ | |
| Humidity | 10% to 95% | ||
| Dimensions | 160(W) x62(H) x200(D) mm. | ||
| Weight | Net: 2200g, Gross: 3500g | ||
Our Advantages
1. Our dvr has the world class anti-vibration technology,widely used in military .It is very long lifetime for over 10 years.
2. We are professional manufacturer,who can offer you great price and technology support.
3. We have a very warm and capable technical team,who can customize many projects for you.We have many examples .Please check our offical website.
4. Great Service.
Application
FAQ
1. Does your MDVR support GPS 3G 4G?
Yes, our MDVR System can be added into GPS WIFI 3G 4G module.
2. Does your Company support OEM or ODM service?
Yes, our company has our own R&D department, and factory , can support OEM & ODM Service.
5. How about your quality control?
We have a very strict quality inspection step , 100% full Quality inspection , total 5 steps:
1):Pre assembly, we check all chips/parts or moudle quality firstly .
2): The sencond time quality inspection when we assembly MDVR /Cameras.
3): The Third time quality inspection when the whole MDVR/Camera assembly well.
4): The Fourth time quality inspection after MDVR/cameras againg by power .
5): The Fifth quaity inspection is selective examination, we wil selective examinate 10% items from different boxes before items
sent out , once there is one item has problem,all items in the boxes must be checked again.
