4CH Dual SD Card MDVR 1080P 4G GPS AI Mobile DVR Driver Fatigue Monitor System

4CH Dual SD Card MDVR 1080P 4G GPS AI Mobile DVR Driver Fatigue Monitor System

Product Details:

Place of Origin: Shenzhen,China
Brand Name: Vanwin Tracking
Certification: CE/FCC/RoHS
Model Number: VW622HD-A

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: negotiated
Packaging Details: Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs .
Delivery Time: 2-3 days for samples,15-30 days for large orders
Payment Terms: T/T or western Union or Paypal;
Supply Ability: 5,000pcs per month
Get Best Price Contact Now

Detail Information
Features: 4G / 3G And GPS Optional, WIFI Auto Download, Basic Monitoring Power Supply: 8V-36V
CVBS: Support Video Input: 4 Channels
Storage Capacity: 2*256G SD Cards Serial Port: Support 2 RS232, 1 RS485
Car Cameras: AHD Up To 2MP 1080P, CVBS D1 Resolution: Support 1080P/720P/D1/CIF
AI Function: ADAS/DSM/BSD Optional Applicable: Bus, Truck, Taxi, Cab, Petrol, Excavator, Mining Truck Fleets
High Light:

4CH SD Card MDVR

,

1080P 4G SD Card MDVR

,

Monitor System AI Mobile DVR

Product Description

High Quality 4CH Dual SD Card 1080P 4G GPS MDVR Driver Fatigue Monitor System ADAS DSM AI Mobile DVR



AI Mobile DVR Features



1) SD card for storage,max 2*128G



2) GPS tracking and 3G/4G remote control realtime monitoring optional



3) UPS technology to protect sudden power off



4) The Power and mainboard are integrated with much better quality



5) G-sensor,RS232/485 interface,RJ45 lan port,6ch alarm input



6) Mini size and light on weight



7) World class anti-vibration technology for over 8 years lifetime



8) High end products for Military dep or government usage



ADAS DSM AI Mobile DVR Specifications



Item
parameters
Audio and Video Inputs
Video input
AHD:4ch 1080/25fps
IPC:Scalable 1-4ch
Audio input
3ch audio input,Mic input
Audio and Video outputs
Video output
Default 1ch CVBS output (VGA output optional)
Audio output
1ch audio output
Audio and video parameter coding
video coding
H.264 Main Profile/H.265
· Resolution
1080P/720P/D1 optional
audio coding
default G.726,G.711A optional
storage space
SD card
support 2 SD card
wireless network
4G wireless
support 1 SIM card,optional:All the major communication modules in the world
WIFI
2.4/5.8Goptional
locate mode
BD/GPS
Positioning, speed detection, time synchronization
Interface
serial port
Support 1 RS232, 1 RS485 can be external sensor
I/O
Support 4 level input, 1 output
network interface
Support external IPC, support hybrid NVR function
USB
USB2.0 interface, support export data, external engineering treasure
· Intercom
1 special intercom hand mark interface
Physical Specifications
Size
135.5mm(L)*137.7mm(W)*36.5mm(H)
Weight
NW:0.5kg
GW:0.75 kg(M16Hv-DGNE- L as a standard)
work environment
· operating Temperature
-20〜+70℃
operating humidity
· 8%〜90%(No condensation)
Other
operator schema
Remote control
· Gravity sensor
Built in G-Sensor
Configurable AI algorithms
Face recognition,eople Counting

4CH Dual SD Card MDVR 1080P 4G GPS AI Mobile DVR Driver Fatigue Monitor System 0


FQA



1.Q: Does the MDVR support Hard drive and SD card?

A: Yes, HDD version MDVR supports SSD, HDD, and SD card. SD card version MDVR supports max 2 SD cardS.

The storage capacity can be from 32GB to 256GB.



2.Q: Is it difficult to install MDVR into the vehicle?

A: Actually it is easy to install it into vehicle. Most driver can figure out how to connect the power cables.

And the camera installation is more easy. Just screw, connect and mount on the target place inside the vehicle.



3.Q: If I need door open and close alarm, overspeed alarm, reverse video, brake video, left-turn video, right-turn video, etc,

is it available?

A: Definitely yes!

The I/O RS232 and 485 extension port is for all expanded purposes, including the functions above.

In fact, there are more customized functions which can be connect through this port, such as Fuel sensor, Counter system,

PTZ camera, and so on.



4.Q: We have our own platform and server, can we use your MDVR? Do you have SDK or can you do customized platform for us?

A: Yes, we have SDK ready and welcome your OEM customized order!



4CH Dual SD Card MDVR 1080P 4G GPS AI Mobile DVR Driver Fatigue Monitor System 1

ADAS warning camera
1. Warning of lane deviation without turn signal
2. Excessive warning of car in front of you
3. Warning of impending collision
4. voice broadcast reminder,Provide real-time voice
6. Adjustable Angle, high temperature resistance

Specifications for ADAS Cameras

Item
Description
Model
VW-ADASM-23
Parameter of Lens
Image sensor
1080P CMOS IMAGE SENSOR
Optical format
1/2.7 inch
pixel
1280H*720V
Pixel size
2.9*2.9um
The output format
MIPI/LVDS
Image output video
Analog HD AHD signal
Wide dynamic
120DB
The lens structure
6G
The aperture
2.0
Lens resolution
6 million pixels
The Angle
Horizontal H: 54°
Vertical V: 35°
The IR filter
650 IR
frequency
trumpet
8Ω/1W
work environment
voltage
12V
current
90 mA±5
temperature
-20 ～ 70℃
Storage temperature
-30 ～ 80℃
Working humidity
45%-80%RH
Store humidity
30%-90%RH
atmospheric pressure
860MBar ～ 1060Mbar
Size
interface
4PIN MicroTCA
Line length
45cm
weight
164g
Structure size
104(L)*57.2(W)*43(H)mm

3G/4G Realtime Monitoring Platform for PC
