AHD 9Inch Quad Car Monitor With Cameras Video Recording 4CH Quad TFT Monitor
Product Details:
| Place of Origin: | Shenzhen,Guandong |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-910HQ-DVR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | negotiated |
| Packaging Details: | Color Neutral Box ; Neutral giftbox,white box and customize box for your option Packing details: Carton Size: 58.2*45.8*34cm N.W:.15.08KG PER CTN G.W: 15.88KG PER CTN 10pcs / ctn |
| Delivery Time: | 3-7 working days |
| Payment Terms: | T/T,Western Union,Paypal; |
| Supply Ability: | 5000 pcs per month; AHD 9Inch Quad Car Monitor With Cameras Video Recording 4CH Quad TFT Monitor |
|
Detail Information |
|||
| Power Supply: | 12V-24V DC Optional | Video Format: | H.264/MPEG-4 Format |
|---|---|---|---|
| Compatible System: | NTSC & PAL (automatically) | Material: | Plastic And Metal |
| Screen Size: | 9 Inch AHD Panel With DVR Quad Picture | Cameras: | 1~4 720P/960P/1080P AHD Cameras |
| Video Input: | 4 Channel AHD Video Input, 1/2/3/4 Image Display Adjustable | Car Make: | Universal Vehicles, Bus, Truck, Other Special Vehicles |
| Trigger: | 4 Trigger | Camera Resolution: | 1280*720px |
| Storage: | SD Card | Installation Method: | Standalone |
| High Light: | 9Inch Quad Car Monitor,4CH Quad TFT Monitor |
||
Product Description
AHD 9Inch Quad Car Monitor With Cameras Video Recording 4CH Quad TFT Monitor
The system can work with 1~4 Analog/720P/960P/1080P AHD cameras to monitor the front, side and back of Truck, Van, Bus, Benz Motor - home, commercial van with quad images. The resolution is very clear and It's widely used in the Truck and Van for reversing and monitoring.
|
Model
|
VW-910HQ-DVR
|
|
Screen
|
9 inch 16:9
|
|
Resolution
|
1024*R.G.B*600
|
|
Back Light Luminance
|
LED, 500cd/m2
|
|
View angle
|
L/R: 180°
UP/Down: 180° |
|
Video Input
|
4-Channel AHD Video Input
Single/2/3/4 Quad Images Adjustable Supporting AHD 720P/960P/1080P Video Compatibility: CVBS /AHD |
|
Audio Input
|
Built-in speaker,1 way audio input(V2)
|
|
Reverse Trigger
|
4 Ways Trigger Priority:V2>V1>V3>V4
|
|
System
|
PAL & NTSC auto-switching
|
|
Power supply:
|
DC 12V-36V input,12V output
|
|
Protection Setting
|
High-low voltage protection & short circuit protection
|
|
Working temperature
|
-20℃ to 70℃
|
|
Storage temperature
|
-30℃ to 80℃
|
|
Housing:
|
Plastic & With Black Rubber Painted
|
|
Accessories
|
Metal U type Bracket & Detachable Sunshade(Default)
Butterfly Bracket/Fan Bracket/ Suction Cup Bracket (optional) |
|
Cable Connector
|
RCA / 4pin connector (Optional)
|
|
Dimension
|
230*155*27(74)mm
|
BNC and 4-pin cable for optional below
Packaging & Shipping
1. Box can be color box, white box, OEM
2. Package includes power line, bracket, remote controller, headrest frame, insert card and user manual.
3. Goods will be shipped out within 2~7 days after the receipt of payment.
