AHD HD IP68 Waterproof GPS CCTV Monitoring Camera 700TVL/800TVL Wired Backup Camera System
Product Details:
| Place of Origin: | Guangdong,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-388 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 5,0000 pcs per month |
|
Detail Information |
|||
| Product Name: | Bus Surveillance Camera | Image Sensor: | CCD 600/700TVL, AHD 720P/960P/1080P |
|---|---|---|---|
| Lens Angle: | 170 Degree Wide Angle | Application: | For Truck Or Bus |
| TV System: | PAL Or NTSC | Power: | DC12 Or 24V |
| Product Features: | GPS CCTV Surveillance Camera | Video Out: | 1CH BNC AHD Output, Support TVI/CVI/CVBS Mode |
| IR Lights: | 24pcs | Working Environment: | -10℃~+60℃, Humidity 95% |
| Highlight: | IP68 Waterproof GPS CCTV Monitoring Camera,700TVL GPS CCTV Monitoring Camera |
||
Product Description
AHD HD IP68 Waterproof GPS CCTV Monitoring Camera 700TVL/800TVL Wired Backup Camera System
This bus surveillance camera with Sonny CCD image sensor has better picture's clarity, color contrasting and sharpness than CMOS camera, and with 24pcs of IR lights, which also shows very clear images at night. It's very popular for buses or trucks management.
Characteristics of truck surveillance cameras:
*Working temperature: -30 ℃~+70 ℃
*AHD standard, CVBS optional
*Light sensor, 18 infrared light-emitting diode lights
*Adopting sunshade and glass design to protect the lens
*Full alloy material design, stainless steel screws
*Waterproof, earthquake resistant, and anti-interference
*Camera 100% nitrogen filled anti fog
*Image type: 1/3-inch color CCD
*Horizontal resolution: 600TVLines
*Effective pixels: PAL: 920L × 582V NTSC: 940L × 494V
*Available lighting: 0Lux (built-in IR LED's for supporting images in the dark)
*Free viewing angle: 130 °
*Waterproof: IP69K Shockproof: 10G
*Video output: 1.0Vp-p75 Ω Power supply: DC12V (from reverse monitor)
*Size: 69 (W) x 43 (H) x 38 (D) mm (not installed)
*The light intensity analyzer ensures that the output light intensity of the LED warning light complies with ES65;
*The patented sealed pressure tester ensures that the waterproof level of the camera and light meets IP69K.
Car reversing camera parameters:
| Chip Technical Parameters | |||
| Image Sensor | 1/4 CMOS H62 100W | Video Out |
1CH BNC AHD output, Support TVI/CVI/CVBS Mode |
| Image System | PAL/NTSC | WDR | auto |
| Resolution | 1280 (H)×720(V) | SNR | >45db |
| Min.illumination | 0.1Lux full color |
White Belance |
AWB |
| Electronic Shutter | 1/25s~1/100,000s | DR | 76db |
| Video Standard | AHD |
Advanced Function |
2D_DNR |
| Frame Rate | 1280×720@25 fps; 1280×720@30 fps; |
Working Environment |
-10℃~+60℃, Humidity 95% |
| Lens | 2.8/3.6mm | Power supply | DC 12V +/-15% |
| Model | VW-388 |
| Image Sensor | CCD |
| Len Angle | 170 Degrees |
| TV System | NTSC/PAL |
| Resolution (TV Line) | 420/480/520 |
| Effective Pixels | 728*582 580*492 |
| Minimum Illumination | 0.1 - 1.0 Lux |
| Waterproof Resistance Rating | IP 68 |
| Power Supply | DV 12V +/- 1V |
| Power Consumption | <1W |
| Video Output | 1.0vpp.75ohm |
| White Balance | Auto |
| AGC | Auto |
| Operating Temperature | -20℃ - 80℃ |
| Storage Temperature | -40℃ - 85℃ |
| Warranty | 15 months |
| Optional Function 1 | Parking Line or not |
| Optional Function 2 | Frontview or Rearview |
| Sample | Available |
| Video Cable Length | 6M |
| Power Supply Length | 1.2M |
Connetor Available for Option
- 4Pin Aviation connector
- DC+RCA connector
- CCTV security BNC connector
Application
The vehicle surveillance camera is widely used in bus, dangerous cargo truck, police car, van, Train, ship, home security etc
for outside.
FAQ:
Q: What is the MOQ ?
A: 1 peice
Q: How fast for sample delivery?
A: 3-7 days
Q: Can I get a lower price if I order large quantities?
A: Yes, the larger the quantity, the cheaper the prices.
Q: How about the warranty period?
A: One year!
Q: How can you guarantee the quality?
A: We have a QC team with 12 years’ experience. All of the products will run through over 4 times’ 100% testing before being delivered.
