IP69K Waterproof Full HD 1080P Auto Vehicle Car Front Camera Car Truck Security Camera
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-775 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 2 pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 50,000pcs per month; |
|
Detail Information |
|||
| Type: | AHD Bus Camera | Lens: | 3.6mm,2.8mm |
|---|---|---|---|
| Resolution: | 1080P | Special Features: | Waterproof,Shockproof,Night Vision,Full HD 1080P |
| Waterproof: | IP69K | IR Leds: | 10 PCS |
| View Angle: | 150 Degree | Sensor: | CMOS,CCD,AHD 1080P |
| Dimensions: | 112.5*75*50(mm) | Warranty: | 12 Months |
| Highlight: | Truck Security Car Front Camera,IP69K Waterproof Car Front Camera,Full HD 1080P Car Front Camera |
||
Product Description
IP69K Waterproof Full HD 1080P Auto Vehicle Car Front Camera Car Truck Security Camera
Product Description
Enhance your driving experience with our state-of-the-art Vehicle Car Front Camera. Designed for safety and convenience, this high-definition camera captures crystal-clear video footage of the road ahead, providing you with valuable evidence in case of accidents and helping you navigate safely.
Key Features:
-
HD Video Quality: Equipped with a 1080p full HD resolution, our front camera ensures that every detail is captured clearly, day or night.
-
Wide-Angle Lens: The 150-degree wide-angle lens provides an extensive field of view, minimizing blind spots and ensuring comprehensive coverage of the road.
-
Loop Recording: The camera automatically overwrites old footage, ensuring continuous recording without the need for manual intervention.
-
G-Sensor Technology: The built-in G-sensor detects sudden movements or impacts, automatically saving the relevant footage to prevent overwriting.
-
Easy Installation: With a user-friendly design, the camera can be easily mounted on your vehicle’s windshield with a secure suction cup.
-
Night Vision: Advanced night vision technology allows for clear footage in low-light conditions, enhancing safety during nighttime driving.
-
Compact Design: Its sleek and discreet design ensures that it blends seamlessly with your vehicle's interior without obstructing your view.
Front Camera Specification:
| Model | JK-AHD-C775 |
| Image Sensor | 1/2.9" progressive scan CMOS |
| Horizontal Resolution | 2.0Megapixel |
| TV system | PAL/NTSC |
| Effective pixels | 1920(H)*1080(V) |
| Minimum Illumination | 0.01Lux@(F1.2,AGC ON),0Lux with IR |
| S/N | ≥40dB |
| Day and night switch | Motor Driver ICR Filter Switch (Magnetic Valve Driver ICR optional) |
| Auto Gain Control | Support |
| Back light compensation | Support |
| White Balance | AUTO |
| Digital Noise Reduction | Adaptive digital noise reduction,2D/3D-DNR |
| Electronic Shutter | AUTO/1/50(1/60)-1(50,000Sec) |
| Video Output | Follow AHD standard |
| Image Function | Original/Reverse image |
| Output Adapter | 4P aviation head cable |
| Lens | 3.6mm(6mm Optional),M12*P0.5 |
| IR LEDS Quantity | 10 PCS Φ5 LEDS |
| IR distance | 10～15 meters |
| IP grade | IP69K |
| Operating Temperature/Humidity | -30°C~+70°C/Humidity≤90%(No condensation) |
| Power Supply | DC12V±10% |
| Power Consumption | ≤2.5W |
| Dimension | 112.5*75*50(mm) |
| Application scenarios: suitable for school bus, container trucks, harvesters, excavators and other side view camera, Mounting rod diameter: Ф20 ~ 30mm | |
Products Details:
Vehicle Car Front Camera Installation Guide
Tools Needed:
- Screwdriver
- Wrench
- Wire strippers
- Electrical tape
- Zip ties
Installation Steps:
-
Preparation:
- Park your vehicle on a flat surface and turn off the ignition.
- Gather all necessary tools and the camera installation kit.
-
Mounting the Camera:
- Identify the ideal location for the front camera, usually above the rearview mirror or on the front bumper.
- Clean the mounting area to ensure a secure attachment.
- Use the provided brackets or adhesive pads to mount the camera securely.
-
Wiring:
- Route the camera's power cable along the vehicle's interior, avoiding any moving parts.
- Connect the power cable to the vehicle's fuse box or battery, ensuring proper polarity.
- If the camera has video output, route the video cable to the display unit (if applicable).
-
Secure the Wires:
- Use zip ties to secure any loose wires, preventing them from getting snagged or damaged.
- Wrap connections with electrical tape for additional protection.
-
Testing:
- Reconnect the vehicle's battery or ignition.
- Turn on the vehicle and ensure the camera powers on and displays a clear image.
-
Final Adjustments:
- Adjust the camera angle for optimal visibility.
- Double-check all connections and mounts to ensure everything is secure.
If you have any questions you don’t understand, you can contact me at any time and I will help you solve the problem.
