Mini 5 Inch Car TFT Monitor 2 Ways AHD 1080P 720P CVBS Mixed Video Inputs with U Shape Bracket
Product Details:
| Place of Origin: | Shenzhen,Guandong |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-M504A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 3 pc |
|---|---|
| Price: | negotiated |
| Packaging Details: | Color Neutral Box ; Neutral giftbox,white box and customize box for your option Packing details: Carton Size: 58.2*45.8*34cm N.W:.15.08KG PER CTN G.W: 15.88KG PER CTN 10pcs / ctn |
| Delivery Time: | 3-7 working days |
| Payment Terms: | T/T,Western Union,Paypal |
| Supply Ability: | 5000 pcs per month ; 9 inch Car Monitor Rear View with TFT LCD Display and Quad Pictures for optional |
|
Detail Information |
|||
| Product Name: | 5 Inch Car Monitor Rear View With TFT LCD Display And Quad Pictures For Optional | Installation Method: | Standalone |
|---|---|---|---|
| Ratio: | 16:9 | Resolution: | 800xRGBx480 |
| Warranty: | 12 Months | Quad Screen: | Optional |
| TV System: | NTSC & PAL (automatically) | Car Make: | Bus,Car,Truck Or Any Vehicle |
| Power Supply: | 9-36V DC/ Output 12V | Power Consumption: | 5W |
| Storage Temperature: | -30〜80℃ | Working Temperature: | -20℃ To 70℃ |
| Highlight: | U Shape Bracket Car TFT Monitor,Mini 5 Inch Car TFT Monitor |
||
Product Description
Mini 5 Inch Car TFT Monitor 2 Ways AHD 1080P 720P CVBS Mixed Video Inputs with U Shape Bracket
Car TFT Monitor Specification
5"inch AHD vehicle mounted display (Detachable sunshade)
| Screen Ratio | 5”high digital new panel ,16:9image |
|
Back Light Luminance /Resolution/ View angel |
LED, 500cd/㎡ /800xRGBx480 /Hor. L(70) R(70) Ver. UP(50) DOWN(70) |
| AV Inputs(standard) | 2 way video input, 2 way audio input,1 ways Trig function, |
| AV Inputs (Optional) | 3 way video input,2 way audio input,3ways Trig function |
| Function(optional) | Light sensor automatic adjustment(optional) |
| Compatible system | NTSC & PAL (automatically) |
| OSD control |
Color, Brightness, Contrast, Volume, Language (English, Deutsch, French, Spanish, Portugal, Italian, Dutch, Simplify Chinese) |
| Image reversion | UP/Down and Left/Right |
| Power requirement | 9-36V DC/ Output 12V |
| Power consumption | 5W |
| Storage temperature | -30〜80℃ |
| Working temperature | -20℃ to 70℃ |
| Size | 140*102*26(56)mm |
| Exterior color | Black rubber oiling |
| Montior And Camera Connector | RCA/ 4pin connector (Optional) |
| Accessories | Remote controller, Power supply cable , User manual, U type bracket |
1. very hot model ,used for rear view system with 1-4 cameras ,or for monitoring system working with car mobile dvr.
2. 5 inch ,7inch ,9inch ,10inch ,12 inch for optional. Quad monitor or normal one
3. One year warranty
4. Full image/2 images/3 images/4 images to show
