4CH 1080P AI Mobile DVR System with GPS Tracker & Vehicle Reverse Camera
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW903AGS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default; |
| Delivery Time: | 1-2 days for samples, 3-10 days for large orders |
| Payment Terms: | Western Union,T/T,Paypal |
| Supply Ability: | 5,000pcs per month; |
|
Detail Information |
|||
| Type: | 4CH DVR ADAS 4G GPS WIFI | AI Function: | ADAS/DMS/BSD Optional |
|---|---|---|---|
| TV System: | PAL Or NTSC | Voltage: | DC 12V |
| Car Make: | Universal, For Any Car | Video Compression Format: | H.265 |
| Warranty: | 12 Months | Length Of Video Cable: | 6M |
| Feature: | 3G/4G/GPS/WIFI | Waterproof: | Support |
| Highlight: | 1080P Vehicle Monitoring Reverse Backup Camera,4CH Vehicle Monitoring Reverse Backup Camera,AI MDVR System Vehicle Gps Tracker |
||
Product Description
4CH 1080P AI Mobile DVR System with GPS Tracker & Vehicle Reverse Camera
Product Overview
VW903AGS is a cost-effective 4CH 1080P AI mobile DVR designed for vehicle video surveillance and remote fleet monitoring. It runs on embedded Linux system with H.264/H.265 video compression for clear and efficient recording.
Key Features
- Video & Audio Recording: 4CH/8CH 720P/1080P real-time monitoring with synchronous audio & video recording
- Storage & Data Protection: Supports 2.5-inch HDD up to 4TB with optional SD card + HDD dual storage and TES error correcting file system
- AI Intelligent Functions: Expandable ADAS/BSD/DSM driving assistance, timing/trigger/manual JPEG snapshot, alarm pre-recording, motion detection & alarm linkage
- Network GPS & Remote Access: Optional built-in 3G/4G/WiFi/GPS with remote video playback and file download
- Vehicle Black Box: Records full driving data including speed, GPS position, G-sensor status, braking, reversing, turning and alarm events
- Industrial Grade Design: Wide voltage DC 8-36V, embedded industrial structure, anti-shock & anti-vibration
Technical Specifications
| Item | Specification |
|---|---|
| Compression Format | H.264 |
| Chip | Hisilicon 3521A(V100) |
| Storage | Max 512G SD card*1 & 2T 2.5-inch HDD*1 (not included) |
| Camera Input Resolution | 1080P/720P/CVBS |
| Video Output | 4CH (CVBS+VGA+HDMI) |
| CMS Server | CMSV6 platform |
| 4G WiFi GPS | Optional |
Product Details
Applications
4CH HDD MDVR works in buses, trucks, trains, forklifts, and other vehicles for comprehensive security video surveillance.
