1080P HD IP Camera with Good Night Vision Vandalproof CCTV Vehicle Inside POE Network Dome Camera for Bus
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-32IP |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral giftbox, with foam plastic bag packed, customize brand is available when order reach 100pcs |
| Delivery Time: | 2-3 days for samples, 5-10 days for large orders |
| Payment Terms: | Western Union, T/T, Paypal |
| Supply Ability: | 5,000pcs per month |
|
Detail Information |
|||
| Style: | Dome Camera | TV System: | PAL Or NTSC |
|---|---|---|---|
| Test Time: | Over 48 Hours | Connector: | 6pin Or RJ45 Port |
| Lens: | 2.1mm/2.8mm/3.6mm/6.0mm | Sensor: | CMOS Or CCD |
| Ir Distance: | 10m | Power: | 12V/ 24V |
| Warranty: | 12 Months | Audio: | Built-in |
| Advantage: | SMT Factory Plus Strict Production | Protocol: | TCP/IP,RTSP,RTP, HTTP,DNS,DDNS,DHCP,FTP,NTP,UPNP |
| Video Compression: | Support H.264/H.265, Dual Stream | ONVIF Protocol: | Standard ONVIF Protocol |
Product Description
1080P HD IP Camera with Good Night Vision Vandalproof CCTV Vehicle Inside POE Network Dome Camera for Bus
Features:
| Module | VW-31IP |
| Sensor | 2MP pixel , 1/2.9″ CMOS sensor |
| Encoding format | H.264, H.265 encoding, support dual stream |
| Maximum frame rate |
PAL: 2M:25fps/s NTSC:2M:30fps/s |
|
Image Resolution |
Main stream: 1920*1080； Auxiliary stream: 704*576,640*480,352*288 Snap stream: 704*576,640*480,352*288 |
| Subtitle overlay | Support channel name, date and time overlay, overlay position is adjustable |
|
Alarm data transmission |
FTP, E-mail, browser, management software |
| Protocol support | TCP/IP,RTSP,RTP, HTTP,DNS,DDNS,DHCP,FTP,NTP,UPNP |
| ONVIF protocol | Standard ONVIF protocol |
| Client browsing | Client browsing supports IE8.0 and above (device embedded Web Server), Edge,Chrome,Safari browser browsing |
| Mobile client | Support iOS, Android platforms |
| Audio format | G.711A |
| Audio input | 1 audio input |
| IR Distance | 10M |
| Lens | 2.8MM M12,fix aperture F2.0, HFOV 110° |
| Proof Grade | IP66 |
| Installation | Installation inside the vehicle |
| Working Temperature | -30℃--＋70℃ |
| Working Humidity | 10-90%RH |
| Interface |
RJ45(POE)Add DC power supply / 6PIN aviation connector/4PIN aviation connector with built-in POE |
| Powered by | Optional DC 12V(PON)/POE(802.3af) |
| Equipment weight | 0.55 kg |
Our advantages
1.We all the time provide car cameras for many car bus truck factories since 12 years ago .We pay much attention to our cameras quality ,adopt A class PCB tech and 4 holes in mainboard completely insulated, isolation of the camera body from excess power, chip not touch camera body, prevent magnetic interference and ensure signal continuity.
2. Careful production Process:
Raw Material---- Accessories High Temperature Test---Assembly----Finished Products----Waterproof Test----High Low Temperature Test(Simulate -60℃to 80℃)----QA Test(IR with function Test ----Packing
3.Strict Tests one by one .
Due to our strict quality control and careful workmanship ,our clients like our cameras very much .Nearly all clients have been cooperating with us all the time .
4.We explore some wide angle or special cameras to meet your requirements that others don't have.
Application
