Max 1000Mbps Wifi 4G Router Wireless Support Hotspot With SIM Card

Max 1000Mbps Wifi 4G Router Wireless Support Hotspot With SIM Card

Product Details:

Place of Origin: Shenzhen, China
Brand Name: Vanwin Tracking
Certification: CE/FCC/RoHS
Model Number: VW-WR1026-5G

Payment & Shipping Terms:

Minimum Order Quantity: 1 peice
Price: Negotiable
Packaging Details: plastic foam packing
Delivery Time: 1-2 days for samples,5~7 days for large orders
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 5000 pcs per day
Get Best Price Contact Now

Detail Information

Max. LAN Data Rate: 1000Mbps Wifi Transmission: 802.11ac
Wired Transfer Rate: 10/100Mbps 2.4G Transmission Rate: 300 Mbps
Type: Wireless Lan Port: 1
Wireless Speed: 150Mbps Encryption Type: WPA2-PSK
Function: Firewall, QoS, VPN Interface: 1 LAN Port, 1*SIM Card Slot, 1*TF Card Slot, 1*USB Port
Standards And Protocol: Wi-Fi 802.11ac,Wi-Fi 802.11b, Wi-Fi 802.11g, Wi-Fi 802.11n Antenna: 2*2.4G Antennas, 2*5G Antennas, 2*4G Antennas
Wireless Speed: 2.4Ghz: 300Mbps; 5.8Ghz: 867Mbps
High Light:

1000Mbps Wifi 4G Router

,

5.8Ghz 867Mbps Wireless Mini Router

,

2.4Ghz 300Mbps Wifi 4G Router

Product Description

Max 1000Mbps Wifi 4G Router Wireless Support Hotspot With SIM Card



Bus Mobile Wifi 4G Router Mini Router Wireless Support Hotspot With SIM Card



Main Features

1. MT7620A chipset, 16MB Flash+128MB RAM (If customer need, here can update to 32MB Flash+256MB RAM)

2. Accept car voltage 8V-28V, you can connect the router with bus voltage directly by the cable (we match it in the product)

3. With watchdog, support dial up Internet automatically after cut off

4. Support flash custom firmware

5. Dual band and support 3G 4G at same time (Install 3G or 4G module is necessary)



Main Specifications

Hardware
Main Chipset MT7620A+7612E
RAM DDR2 128MB (Max 256MB)
FLASH 16MB (Max 32MB)





Antenna

7 external 5dbi OMNI antennas

(4 for Wi-Fi antennas, 2 for 3/4g module antenna, 1 for GPS antenna, the details need according to customer’s requirements)

Interface 1* 10/100M Auto MDI/MDIX LAN
Button Reset
LED Power,WLAN,LAN,3G/4G,USB,5G
Power Input 12V 1A(9-28V)
Consumption <=15W
Product Size 125.5*100.5*25mm
Wireless





Protocol Standard

IEEE 802.11n,

IEEE 802.11g,

IEEE 802.11b,

IEEE 802.11a,

IEEE 802.11ac

Wireless Rate

2.4GHz: Up to 300Mbps

5.8GHz: Up to 900Mbps

Work Frequency

2.4G:2412 MHz-2484MHz(channel 1 -channel 14).

5.8G: 5725MHZ-5850M(channel:149, 153, 157, 161, 165)

RF Output Power

802.11b 18dBm±2dBm

802.11g 15dBm±2dBm

802.11n 15dBm±2dBmu

802.11a 20dBm±2dBm

802.11ac 20dBm±2dBm





Receive sensitivity

802.11b <=-76dBm

802.11g <=-65dBm

802.11n <=-61dBm

802.11a <=-64dBm

802.11ac <=-59dBm

PPM ±10
Distance 50 Meters radio
QTY of current users 45-55users



Wi-Fi security

64/128/152 WEP

WPA-PSK/WPA2-PSK

WPA/WPA2 Security system

Software
Firmware MTK SDK;OPENWRT
Work Mode AP; ROUTER; WDS; Bridge
WAN PPPoE, Dynamic IP, Statics IP



DHCP

DHCP server
Client table
Statics IP
Virtual Server Port transfer and store.
DMZ



Security

Client Filter
Mac Filter
URL Filter
Remote Website Management
DDNS Support
QOS Support
Statics IP Support
Sys Log Support
Style Change Support
Others



Work Environments

Operating Temperature: -20℃ ~ 70℃
Storage Temperature: -40℃~ 70℃

Operating Humidity: 10%~90% non-condensing
Storage Humidity: 10%~90% non-condensing

Max 1000Mbps Wifi 4G Router Wireless Support Hotspot With SIM Card 0

Max 1000Mbps Wifi 4G Router Wireless Support Hotspot With SIM Card 1



Why you need 4G Router?



1. Portable Usage for Travel, Home, and Business
4G Smart router brings all of your workplaces under a digital roof with a secure VPN.

It can connect your global offices with 4G Smart router.

so the staff from all locations can communicate with teach other remotely and all data is shared securely.

You don’t need to think about how your workplaces might change your network preference.



2. LARGE STORAGE COMPATIBILITY
4G Smart router has a built-in MicroSD slot that supports maximum 128GB MicroSD card. With the extra storage, you can create a local network drive in order to store data and share them with your laptop and other compatible devices as long as it is connected to the Wi-Fi.


3. Interchangeable Module Tailored to Your Needs
4G Smart router is easily configurable and has a built-in interchangeable module for full optimization. It is compatible with CAT4 and CAT6 modules from various brands.


4. VPN SERVICE PROVIDERS FOR YOUR SELECTION
Work or Play Securely Anywhere, and Anytime
Apart from its powerful built-in firewall, microuter also supports OpenVPN, WireGuard and customized DNS server in order to level up your online security. With our brand-new Web UI 3.0, you can set up VPN server easily and access your files securely and remotely as if you were at home.



For different country need to match different 3G or 4G module, the below information is for your reference.



3G(Most country):

•UMTS/HSPA+
Dual Band(MU709s-2)
Tri Band(MU709s-6)
•EDGE/GPRS/GSM Quad-band



4G(For Europe, Some of Asia Country, Africa)

FDD LTE: B1/B3/B5/B7/B8/B20

TDD LTE: B38/B40/B41

WCDMA: B1/B5/B8

GSM: 900/1800



4G(For Australia)

FDD LTE: B1/B3/B5/B7/B28

WCDMA: B1/B5



4G(For America)

FDD LTE: B2/B4/B12

WCDMA: B2/B4/B5



4G(For America)

FDD_LTE: • Band2(1900MHz)
• Band 4(1700/2100 MHz)
• Band 5 (850 MHz)
• Band 13 (700 MHz)
• Band 17 (700 MHz)
• Band 25 (1900 MHz) UMTS (WCDMA)/HSDPA
/HSUPA/HSPA+/DC-HSPA+: • Band 1 (2100 MHz)
• Band 2 (1900 MHz)
• Band 4 (1700/2100MHz)
• Band 5(850 MHz)
• Band 8 (900 MHz) EVDO/CDMA:( 800 MHz)
• BC1 (PCS 1900 MHz)
• BC10 (800 MHz) GSM/GPRS/EDGE GNSS: • GPS: 1575.42 MHz
• GLONASS: 1602 MHz



4G(For America)

LTE(B1--B5, B7,B12,B13,B20,B25,B26,B29,B30,B41);

WCDMA(B1,B2,B3,B4,B5,B8);

TD-SCDMA; CDMA 1XRTT/EV-DO Rev A; GSM/gprs/edge
