1080P 4 Channel AHD dual SD MDVR mobile vehicle dvr system
Product Details:
| Place of Origin: | China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE ROHS |
| Model Number: | VW9504 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | USD100-USD300 |
| Packaging Details: | Neutral package, carton box |
| Delivery Time: | 3-15days upon payment |
| Payment Terms: | T/T, Western Union,paypal |
| Supply Ability: | 1000PCS/month |
|
Detail Information |
|||
| Video Compression: | H. 264 | Storage: | One SD Card, Max 256GB |
|---|---|---|---|
| Resolution: | Support 1080P/720P/D1/CIF | Product Name: | 4ch Mobile Dvr Support 3g 4g Gps Mdvr |
| Warranty: | 18 Months | Type: | 1080P 4 Channel AHD Dual SD MDVR Mobile Vehicle Dvr System |
| Video Input: | 4 Channels AHD 1080P Video | Power Input: | DC 8V~36V |
| Gps: | YES | Playback: | Single/4 Pictures/ Customized |
| Language: | English/Chinese/Russian | Alarm Input: | 4CH Alarm Inputs |
| Channel: | 4CH | 4g: | 4G Optional |
| Applicable Vehicles Type: | Concrete Mixers, Blenders, Cement Mixers | Extensive Functions: | Fuel Tank Monitoring, Driving Turning Monitoring, Blindspot Alarm |
| Highlight: | SD Card Mobile Dvr 4 Channel,Double SD Card Mobile Dvr,SD Card Mobile Dvr DC36V |
||
Product Description
1080P 4 Channel AHD dual SD MDVR mobile vehicle dvr system
Product advantages
- The on-board interface can operate reliably and stably in complex environments
- Video encoding H.265, H.264 is optional
- Support 4G, GPS, WIFI function modules
- Rich peripheral interfaces
- Support UI human-computer interface
- Support dual SD card storage
- Support remote system maintenance
Product Parameter
-
Item parameters Audio and Video Inputs Video input AHD:4ch 1080/25fps
IPC:Scalable 1-4ch
Audio input 3ch audio input,Mic input Audio and Video outputs Video output Default 1ch CVBS output (VGA output optional) Audio output 1ch audio output Audio and video parameter coding video coding H.264 Main Profile/H.265 · Resolution 1080P/720P/D1 optional audio coding default G.726,G.711A optional storage space SD card support 2 SD card wireless network 4G wireless support 1 SIM card,optional:All the major communication modules in the world WIFI 2.4/5.8Goptional locate mode BD/GPS Positioning, speed detection, time synchronization Interface serial port Support 1 RS232, 1 RS485 can be external sensor I/O Support 4 level input, 1 output network interface Support external IPC, support hybrid NVR function USB USB2.0 interface, support export data, external engineering treasure · Intercom 1 special intercom hand mark interface Physical Specifications Size 135.5mm(L)*137.7mm(W)*36.5mm(H) Weight NW:0.5kg
GW:0.9kg(M16Hv-DGNE- L as a standard)
work environment · operating Temperature -20〜+70℃ operating humidity · 8%〜90%(No condensation) Other operator schema Remote control · Gravity sensor Built in G-Sensor
Product Photos
Platform Sceenshot
