Portable GPRS OBD GPS Tracker With Remote Monitoring
Product Details:
| Place of Origin: | China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE ROHS |
| Model Number: | VW01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | USD5-USD70 |
| Packaging Details: | Neutral package, carton box |
| Delivery Time: | 3-15days upon payment |
| Payment Terms: | L/C, T/T, Western Union,paypal |
| Supply Ability: | 1000PCS/month |
|
Detail Information |
|||
| Product Name: | GPRS OBD GPS Tracker | Network: | GPRS, GSM |
|---|---|---|---|
| OBD Port: | Support 16 Pin Standard OBDII Port. | GPS Chipset: | MTK High Sensitivity Chip |
| Working Voltage: | 9-36V DC | Working Temperature: | -20°C To +70°C |
| Locate Mode: | GPS+LBS+AGPS | Extra Features: | Remote Voice Listening(optional) |
| Highlight: | 9V DC Portable GPS Tracker,GPRS OBD GPS Tracker,36V DC Portable GPS Tracker |
||
Product Description
Portable GPRS OBD GPS Tracker with remote monitoring
INTRODUCTION
This product uses GSM/GPRS network and satellite positioning system to manage or monitor remote targets. Widely used in: vehicle rental/fleet management/logistics transportation/vehicle anti-theft, etc. Please make sure to read this user manual carefully before use. Accessories are subject to change without prior notice.
SPECIFICATION
| Specification | Parameters |
| Network | GSM/GPRS |
| Frequency | 850/900/1800/1900Mhz |
| Dimension | 50*38*25mm |
| OBD Port | Support 16 pin standard OBDII port. |
| Locate mode | GPS+LBS+AGPS |
| GPS chipset | MTK high sensitivity chip |
| Working voltage | 9-36VDC |
| Working Temp. | -20°C to +70°C |
| Time To First Fix(open sky) |
Cold status <35s Hot status <1s |
| GPRS Protocol | Class12, TCP/IP |
FUNCTIONS INTRODUCTION
