GPS 1080P HD 4CH Mobile DVR  SD Card Samrt WIFI Bus Vehicle Digital Video Recorder

GPS 1080P HD 4CH Mobile DVR SD Card Samrt WIFI Bus Vehicle Digital Video Recorder

Product Details:

Place of Origin: Shenzhen,China
Brand Name: Vanwin Tracking
Certification: CE/FCC/RoHS
Model Number: VW604

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: negotiated
Packaging Details: Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs .
Delivery Time: 2-3 days for samples,15-30 days for large orders
Payment Terms: T/T or western Union or Paypal
Supply Ability: 5,0000 pcs per month
Get Best Price Chat Now

Detail Information

Video Compression Format: H.264 Weight: 1.1 KG
Input Voltage: DC:+8V - +36V Output Voltage: +12V@1.5A,+5V@1.5A
Alarm Input: 4 Level Alarm Inputs Humidity: 20% - 80%
Certification: CE/FCC/RoHS Temperature: -20℃ - +70℃
Communication Interface: Optional 1 RS232 Or 1 RS485 OSD: Support For Time, Date, Vehicle ID, Image, Etc.
Highlight:

4CH Mobile DVR

,

1080P Mobile DVR

,

WIFI Mobile DVR

Product Description

GPS 1080P HD 4CH Mobile DVR SD Card Samrt WIFI Bus Vehicle Digital Video Recorder




Product features
1. H.264 video compression, multi code stream.
2. Support 4CH 1080P/720P HD real-time video inputs. Also, support 4CH analog
cameras inputs or compound inputs for 2CH HD cameras and 2CH analog cameras.
3. 1CH VGA output is optional.
4. With exclusive pre-allocated type vehicle file system technology, it solved the file
fragmentation problems which caused by overwrite, SD card data loss and SD card
couldn’t be found, keep the data completed and stable.
5. 8-36V wide voltage power supply, super low power consumption. With overload/
under voltage/ short-circuit/ reversing protection, support all vehicles.
6. Support dual SD cards, at maximum 256G for single SD card
7. With watchdog abnormal restart protection function, it can better protect the machine
and video.
8. Delayed video recording functions when vehicle is shut down (time settings can be up
to 24 hours).
9. Various video recording modes to meet different demands, such as automatic
recording, manual recording, alarm recording, etc.
10.Support 4CH alarming inputs and 1CH independent alarm input.
11.Optional for 1CH RS232 Serial port or 1CH RS485 extension.
12.Support GPS/G-Sensor.
13.Support remote operation and monitoring by 3G and 4G.
14.Support Wi-Fi and automatic data download.
15.Support ministry of communications agreement, support SMS remote configuration
and equipment control.
16.Support voice broadcast, intercom and text schedule dispatch.
17.Support fuel sensor, temperature sensor, POS, LED advertising screen.
18.Support shockproof aviation connector, easy to plug or pull out, with best quality and
best price, stable and reliable.
19.With full enclosed lock design, it can prevent the man-made sabotage effectively;
Support mouse operating.
20.Support all vehicles, including bus, taxi, truck, school bus, etc.


Parameters:

  File System FAT32 exclusive file system



Video Playback

Video Search Search recorded video files by recording time and recording method
Playback Support at max 4 channel synchronous playback, suspend, forward, backward
Support 2/4/8/16 times speed forward or backward
Security Management User Password or administrator password management, support screen locked



Expansion functions

TTS Voice broadcast Support TTS voice broadcast
Series port expansion Support external equipment connecting for advertising screen, PTZ control, fuel sensor, etc

Power and

Consumption

Power Management

Self-adaptive wide voltage input, with protect functions for overload, under voltage, short circuit, reversing connection, etc

Support time setting startup/shutdown, delayed power off function





Power and Consumption

Input Voltage DC:+8V - +36V
Output Voltage +12V@1.5A,+5V@1.5A
Power-off Protection UPS technology to protect all recorded information automatically and make sure the files undamaged in case of sudden power off.
Consumption Normal working < 14W, standby < 0.5W
Working environment Temperature -20℃ - +70℃
Humidity 20% - 80%



SD Card Type Series

Dimension 150*137*60MM
Weight 1.60KG



GPS 1080P HD 4CH Mobile DVR  SD Card Samrt WIFI Bus Vehicle Digital Video Recorder 0







GPS 1080P HD 4CH Mobile DVR  SD Card Samrt WIFI Bus Vehicle Digital Video Recorder 1










GPS 1080P HD 4CH Mobile DVR  SD Card Samrt WIFI Bus Vehicle Digital Video Recorder 2







FAQ

1.Q: Does the MDVR support Hard drive and SD card?

A: Yes, HDD version MDVR supports SSD, HDD, and SD card. SD card version MDVR supports max 2 SD card.

The storage capacity can be from 32GB to 2TB.

2.Q: Is it difficult to install MDVR into the vehicle?

A: Actually it is easy to install it into vehicle. Most driver can figure out how to connect the power cables.

And the camera installation is more easy. Just screw, connect and mount on the target place inside the vehicle.

3.Q: If I need door open and close alarm, overspeed alarm, reverse video, brake video, left-turn video, right-turn video, etc,

is it available?

A: Definitely yes!

The I/O RS232 and 485 extension port is for all expanded purposes, including the functions above.

In fact, there are more customized functions which can be connect through this port, such as Fuel sensor, Counter system,

PTZ camera, and so on.

4.Q: We have our own platform and server, can we use your MDVR? Do you have SDK or can you do customized platform for us?

A: Yes, we have SDK ready and welcome your OEM customized order!
