Free CMS software GPS Mobile DVR , CCD cameras 3G WIFI Car DVR

Free CMS software GPS Mobile DVR , CCD cameras 3G WIFI Car DVR

    • Free CMS software GPS Mobile DVR , CCD cameras 3G WIFI Car DVR
    • Free CMS software GPS Mobile DVR , CCD cameras 3G WIFI Car DVR
    • Free CMS software GPS Mobile DVR , CCD cameras 3G WIFI Car DVR
    • Free CMS software GPS Mobile DVR , CCD cameras 3G WIFI Car DVR
  • Free CMS software GPS Mobile DVR , CCD cameras 3G WIFI Car DVR

    Product Details:

    Place of Origin: Shenzhen,China
    Brand Name: Vanwin Tracking
    Certification: CE/FCC/RoHS
    Model Number: VW612GSW

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pc
    Price: negotiated
    Packaging Details: Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs .
    Delivery Time: 2-3 days for samples,15-30 days for large orders
    Payment Terms: T/T or western Union or Paypal
    Supply Ability: 5,000pcs per month
    Contact Now
    Detailed Product Description
    Power Supply: 8V-36V Storage Capacity: SD Card, Max Support 2*128GB
    Basic Function: 8 Cameras Monitoring With 3G Real Time,GPS Tracking,Wi-Fi Software Support: Client,Server,Playback Software
    Car Make: Bus,Truck,School Bus,Tailer,Petrol Cars And So On Quality: The World Class Anti-vibration Technology
    H.264 Format: YES Agents: Welcome
    Recording: 8ch Full D1 Recording RJ45: Support

    Free CMS software bus DVR CCD cameras video recording bus mobile DVR


    The MDVR allows you to track and view your vehicles in REAL TIME via live video camera streaming from up to 8 cameras on your truck, car ,bus,taxis, police cars, excavators, petorl trucks, law enforcement vehicles, and other various types of vehicles with people counting,RFID card reader,fuel consumption sensor,LED display functions etc.


    Using the Internet, GPS, and Mobile CCTV technology, you can now view your vehicles, drivers and cargo from your office, wherever they are in the country. Our cloud-based Control Room software also allows you track your fleet, identifying speed, location, fuel-level and many more.


    Vehicle Tracking that lets you SEE the FULL picture.


    Main Features


    1)  8CH, Support 8 cameras

    2) H.264 compression format

    4)  Dual Sd cards recording

    5) GPS tracking

    6) 3G remote control

    7)  Built-in WIFI for option

    8) 6 alarm input, 1 alarm output

    9) 2 way intercom

    10) Remote oil&power cut-off

    11) Mirror recording in SD card

    12) Patent UPS continuously working to protect data upon sudden power-off

    13) Customiz more function

    14) Built-in Heater(optional)

    15) Lockable, metal HDD handle, protect HDD efficiently

    16) Watermark and Time/Date stamp in exported images




    Item Description
    OS Linux
    Graphics Operation Interface System parameters can be set through external display and remote controller
    Security Management 2-level management for user password, administrator password, supporting encrypted transmission
    Video and Preview Video Input, Output 8-channel video input, 1channel video output; 1.0Vp-p, 75Ω
      OSD Character superposition function, information superposition of time and date, device ID and GPS, etc.
      Video Compression Format Compression coding. Applying Hisilicon hi-performance processor.
      Dual-Stream Supported
      Preview Function Preview of 1-channel, 4-image stitching, supporting full screen triggered by event and switching of stitched images
      Frame Rate PAL: 100 frames/s, up to 25 frames/s per channel; NTSC: 120 frames/s, up to 30 frames/s per channel
      Resolution CIF, HD1 and D1 for selection, supporting 2 channels of D1+ 2 channels of CIF at the most
      Quality Grade 1 to grade 5 for selection (descending)
      Bit Rate CIF: 256Kbps ~ 1.5 Mbps, 8-level bit rates for selection
    HD1: 600Kbps ~ 2 Mbps, 8-level bit rates for selection
    D1: 800Kbps ~ 3Mbps, 8-level bit rates for selection
    Audio Audio Input, Output 8-channel input, 1-channel output
      Compression Format G.726 coding
    Recording Storage Medium Supporting dual SD cards, which supports up to 256GB
      File Format/ System ASF/FAT32
      Video Strategies Recording at startup by default, supporting timed recording, recording triggered by alarm and event, as well as manual recording
      Video Search Searching by time, type, storage device and other conditions
      Video Playback Supporting playback on local device, supporting synchronous playback of up to 8 channels and analysis on vehicle information in the files
        Supporting fast forward, fast backward, play and pause, supporting fast forward and fast backward at 2x, 4x, 8x and 16x speed, supporting file play from selected time
    Alarm Alarm Input/ Output 6-channel on/off signal alarm input, 1-channel on/off signal alarm output
      Alarm Recording Prerecording function 15 seconds before alarm, duration of recording after alarm can be adjusted from 30s ~ 30min
      Storage Space Alarm Supporting settings for alarm of storage space
      Function Alarm GPS overspeed alarm, acceleration alarm, motion detection alarm
    Communication Ports RS232,
    Wireless Transmission (Optional) Embedded 3G wireless transmission module, WCDMA, CDMA2000, TD-SCDMA system for selection;
    Compatible with GPRS, EDGE;
    GPS (Optional) Supporting external GPS, WIFI download
    Remote Data Transmission Channel Selection Supporting 3G; supporting remote downloads of back-end recording strategies;
    PTZ Control Supporting PTZ control realized by local ad client software;
    Parameter Configuration Supporting parameter configuration functions for mobile DVR coding channel;
    G-Sensor Embedded
    System Upgrading Supporting SD card, hard drive upgrading and remote upgrading
    Power Supply and Power Consumption Power Supply 1. ACC on/off
    2. Hard drive lock on/off
    3. Delayed shutdown
    4. Timed on/off
      Input Voltage DC:+8V ~ +36V
      Output Voltage +12V@4*A
      Power-off Protection With patented UPS power supply continuous working technology, it can work for 3~5 seconds after external power supply is cut so that the intactness of video data can be kept upon sudden power failure
      Power Consumption <10W in normal operation; <0.5W in standby mode
    Operating Environment Temperature Normal: 0℃ ~ +60℃; upon hard drive preheating: -25℃ ~ +60℃
      Humidity 10% to 95%




    1. What about my family being recorded when using my vehicle for private use?

    Re: The unit is completely secure of unauthorised access and the data cannot be viewed unless an event calls for data recovery. In other words, no one can access the data unless a prior event has called for a data recovery for the time and date stamp of the event. Only the data for this time and date stamp will be recovered and the data will then be able to be used as evidence.


    2. Who has authority to see the data?

    Re: requesting authority includes the Police, local authority (council), Insurance Company and any legal representative working on the owner's behalf.


    3. Can I disable the video and audio recording?

    Re: No, the recorder is encrypted and locked down and cannot be accessed unless an authorised person has been called to access the data.


    4. Does the system work 24/7?

    Re: Yes, and the standard system works off the ignition switch only which saves the battery of the vehicle from draining.


    5. Does the recorder offer GPS, speed, 3G, WIFI, G sensors?

    A Yes, these are optional extras which can be selected at times of purchase.
