4G HDD SD GPS Bus Vehicle Mobile DVR Recorder 720P with Panic Button

4G HDD SD GPS Bus Vehicle Mobile DVR Recorder 720P with Panic Button
4G HDD SD GPS Bus Vehicle Mobile DVR Recorder 720P with Panic Button 4G HDD SD GPS Bus Vehicle Mobile DVR Recorder 720P with Panic Button 4G HDD SD GPS Bus Vehicle Mobile DVR Recorder 720P with Panic Button 4G HDD SD GPS Bus Vehicle Mobile DVR Recorder 720P with Panic Button

Large Image :  4G HDD SD GPS Bus Vehicle Mobile DVR Recorder 720P with Panic Button

Product Details:
Place of Origin: Shenzhen,China
Brand Name: Vanwin Tracking
Certification: CE/FCC/RoHS
Model Number: VW619HD
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: negotiated
Packaging Details: Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs .
Delivery Time: 2-3 days for samples,15-30 days for large orders
Payment Terms: T/T or western Union or Paypal
Supply Ability: 5,000pcs per month

4G HDD SD GPS Bus Vehicle Mobile DVR Recorder 720P with Panic Button

Description
Video Format: H.264 Network Port: RJ45
WIFI Download: Support AHD Camera: 720P/960P
Passenger Video Counter: Optional G-Sensor: Embedded
Alarm: 6CH Alarm Inputs, 2CH Alarm Output Resolution: 4ch 720P(1280x720), 960p
Product Name: 4ch HDD Mobile Dvr Support 3g 4g Wifi Gps Mdvr Language: English/Chinese/other Language Can Be Customized
Software Support: Client For PC And Mobile Phone, Server, Playback Software Application: Bus, Truck, Taxi, Cab, Petrol, Excavator, Mining Truck Fleets
High Light:

3g cctv dvr

,

car mobile dvr

4G HDD SD GPS Bus Vehicle Mobile DVR Recorder 720P with Panic Button

It is designed for all commercial vehicles, especially those that carry passengers. To discover how the system can be constructed to suit your requirements, contact us for a no obligation consultation.



Main Features

  1. 4 Channel*720P or 1080P
  2. It can support Analog or any AHD cameras
  3. RS232 and RJ45 lan port
  4. H.264 compression format
  5. 2.5“ SATA 1TB Hard disk
  6. GPS tracking
  7. 3G remote control
  8. Built-in WIFI for option
  9. 4CH full 720P/D1 recording
  10. 6 alarm input, 2 alarm output
  11. 2 way intercom
  12. Remote oil&power cut-off
  13. Mirror recording in SD card
  14. Patent UPS continuously working to protect data upon sudden power-off
  15. Customized GPS data format sending(optional)
  16. Built-in Heater(optional)
  17. Lockable, metal HDD handle, protect HDD efficiently
  18. Watermark and Time/Date stamp in exported images

Our Service



1. Server --- First year is free. We can also help to build up your own Server. Welcome to talk.


2. CMS Platform --- iFAR is our brand name of softwares. Copyright protection. Free platform. It can support PC and Mobile phone.

3. Player --- Free Player.

4. Software --- iFAR is free. Welcome OEM customized project.

5. Technology support --- We provide Installation guiding, Problem solving, Remote upgrading etc.

6. Warranty --- We provide 12 months quality warranty based on normal use.



Main Specifications

Item Description
OS Linux
Graphics Operation Interface System parameters can be set through external display and remote controller
Security Management 2-level management for user password, administrator password, supporting encrypted transmission
Video and Preview Video Input, Output 4-channel video input, 1channel video output; 1.0Vp-p, 75Ω
OSD Character superposition function, information superposition of time and date, device ID and GPS, etc.
Video Compression Format Compression coding. Applying hisilicon hi-performance processor.
Dual-Stream Supported
Preview Function Preview of 1-channel, 4-image stitching, supporting full screen triggered by event and switching of stitched images
Frame Rate PAL: 100 frames/s, up to 25 frames/s per channel; NTSC: 120 frames/s, up to 30 frames/s per channel
Resolution CIF, HD1 and D1 for selection, supporting 2 channels of D1+ 2 channels of CIF at the most
Quality Grade 1 to grade 5 for selection (descending)
Bit Rate

CIF: 256Kbps ~ 1.5 Mbps, 8-level bit rates for selection

HD1: 600Kbps ~ 2 Mbps, 8-level bit rates for selection

D1: 800Kbps ~ 3Mbps, 8-level bit rates for selection

Audio Audio Input, Output 4-channel input, 1-channel output
Compression Format G.726 coding
Recording Storage Medium Supporting one 2.5” hard drive and one SD card, which supports up to 32G, supporting data redundancy storage technology;
File Format/ System ASF/FAT32
Video Strategies Recording at startup by default, supporting timed recording, recording triggered by alarm and event, as well as manual recording
Video Search Searching by time, type, storage device and other conditions
Video Playback Supporting playback on local device, supporting synchronous playback of up to 4 channels and analysis on vehicle information in the files
Supporting fast forward, fast backward, play and pause, supporting fast forward and fast backward at 2x, 4x, 8x and 16x speed, supporting file play from selected time
Alarm Alarm Input/ Output 6-channel on/off signal alarm input, 1-channel on/off signal alarm output
Alarm Recording Prerecording function 15 seconds before alarm, duration of recording after alarm can be adjusted from 30s ~ 30min
Storage Space Alarm Supporting settings for alarm of storage space
Function Alarm GPS overspeed alarm, acceleration alarm, motion detection alarm
Communication Ports RS232, RJ45 10M/100M self-adaptable network interface
Wireless Transmission (Optional) Supporting Wi-Fi;
GPS (Optional) Supporting external GPS
PTZ Control Supporting PTZ control realized by local;
Parameter Configuration Supporting parameter configuration functions for mobile DVR coding channel;
G-Sensor Embedded
System Upgrading Supporting SD card, hard drive upgrading and remote upgrading
Power Supply and Power Consumption Power Supply

1. ACC on/off

2. Hard drive lock on/off

3. Delayed shutdown

4. Timed on/off

Input Voltage DC:+8V ~ +36V
Output Voltage +12V@4*0.5A; +5V@0.5A
Power-off Protection With patented UPS power supply continuous working technology, it can work for 3~5 seconds after external power supply is cut so that the intactness of video data can be kept upon sudden power failure
Power Consumption <10W in normal operation; <0.5W in standby mode
Operating Environment Temperature Normal: 0℃ ~ +60℃; upon hard drive preheating: -25℃ ~ +60℃
Humidity 10% to 95%
Dimensions 160(W) x62(H) x200(D) mm.
Weight Net: 2200g, Gross: 3500g
