2 Doors People Counter Accuracy 98 % Automatic Wireless Visitor Counting Device For Bus
Product Details:
Place of Origin: | Shenzhen,China |
Brand Name: | Vanwin Tracking |
Certification: | CE/FCC/RoHS |
Model Number: | VW9034BGS |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | negotiated |
Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
Delivery Time: | 2-3 days for samples,15-30 days for large orders |
Payment Terms: | T/T or western Union or Paypal |
Supply Ability: | 50,000pcs per month; |
Detail Information |
|||
Product Name: | Intelligence Two Door Bus People Counter | Type: | Passenger Counter |
---|---|---|---|
Scanning Style: | 3d Scanning | Color: | Black |
Resolution: | 720P/960P/1080P | Real-Time Monitoring: | Live Tracking Of Passenger Flow |
Power Supply: | DC 8V - DC 32V | Application: | Bus,Vehicle,School Bus |
Highlight: | Automatic Wireless Visitor Counting Device,2 Doors Visitor Counting Device,People Counter For Bus |
Product Description
Pepole Counter System Description
2 Doors People Counter Accuracy 98% Automatic Wireless Visitor Counting Device For Bus
The Dual-Door People Counter Mobile DVR System is an advanced, all-in-one solution designed to seamlessly integrate crowd management and surveillance for businesses, public venues, and high-traffic areas. Combining real-time people counting, video monitoring, and mobile accessibility, this system empowers users to optimize operations, enhance security, and make data-driven decisions.
Pepole Counter System Key Features
Dual-Door Precision Counting
- Accurately tracks foot traffic in real-time across two separate entry/exit points using advanced infrared or 3D stereo-vision sensors.
- Eliminates double-counting with directional detection (in/out) and provides occupancy alerts to prevent overcrowding.
Integrated Mobile DVR Surveillance
- High-definition IP cameras (1080p/4K) with wide-angle lenses capture clear footage of both doors and surrounding areas.
- Onboard storage (up to 2TB HDD) and cloud backup ensure continuous recording, even during network interruptions.
- Remote access via iOS/Android apps or web browsers for live viewing, playback, and evidence extraction.
AI-Powered Analytics
- Generate automated reports on visitor trends, peak hours, and dwell time for space optimization and staffing adjustments.
- Optional facial recognition, heatmaps, and loitering detection for enhanced security insights.
Flexible & Mobile Deployment
- Compact, weatherproof design (IP66-rated) suits indoor/outdoor use in retail stores, transit hubs, events, or temporary setups.
- Supports 4G/Wi-Fi connectivity and PoE (Power over Ethernet) for easy installation without complex wiring.
Smart Alerts & Integration
- Instant notifications for capacity breaches, unauthorized access, or suspicious activity via SMS, email, or app.
- Compatible with POS systems, access control, and third-party analytics platforms for unified management.
Pepole Counter System Main Specifications
Item
|
Parameter
|
Description
|
System
|
Operational language
|
Chinese. English, Others (customizable)
|
Operation interface
|
Graphical menu operation interface (OSD menu)
|
|
Password security
|
Two-level management of user password and
administrator password |
|
Video
|
Video input
|
4/8 video input
|
Video output
|
There are two video output modes of VGA and aviation head interface
|
|
Video resolution
|
Support 1080P. 720P, D1, HD1, CIF, etc
|
|
Video loop recording
|
Support SD card automatic loop recording and loop overlay (auto default)
|
|
Video mode
|
Support boot recording, timing recording, alarm (trigger) recording
|
|
Image compression
|
H264/H265
|
|
Display
|
Preview features
|
Supports single and multi-view
|
OSD overlay display
|
Channel name, time, recording status, resolution, license plate, GPS information, etc
|
|
Alarm
|
IO alarm
|
4 IO alarm inputs, with alarm linkage function
|
Communication interface
|
RS232 interface
|
1CH RS232, expandable card machine, oil sensor, LED advertising screen, etc
|
RS485 interface
|
1-way 485 interface, expandable gimbal
|
|
AI capabilities
(Extensible) |
Passenger counting
|
1 door passenger counting
|
2 doors passenger counting
|
||
3 doors passenger counting
|
||
4 doors passenger counting
|
||
DMS
|
Fatigue (closed eyes, hatcher) detection alarm
|
|
Occlusion camera detection alarm
|
||
Receiving and receiving phone calls to detect alarms
|
||
Face loss detection alarm
|
||
Distraction detection alarm
|
||
Smoking detection alarm
|
||
ADAS
|
Occlusion camera detection alarm
|
|
Lane departure detection alarm
|
||
Pedestrian detection warning
|
||
Vehicle distance detection and warning
|
||
BSD
|
Left blind zone detection alarm
|
|
Right blind zone detection alarm
|
||
Platform
|
Remote monitoring
platform |
Real-time monitoring, monitoring intercom, playback, video, high-definition screenshots, GPS data, alarm data upload
|
Others
|
Power consumption
|
≤10W
|
Operating temperature
|
-20ºC to +70ºC
|
|
Operating humidity
|
20% to 80%
|
|
Size
|
161 (D)* 159(W)* 63(H) mm
|
|
Net weight
|
1.119KG
|
|
Power input
|
DC +10V - +36V
|
Pepole Counter System Photos
FAQ:Pepole Counter System
Q1. What is the purpose of a 2 Doors People Counter Mobile DVR System?
The system is designed to count the number of people entering and exiting through two doors, providing accurate traffic data for businesses and venues.
Q2. How does the people counter work?
The system uses infrared sensors or video analytics to detect and count individuals as they pass through the designated doors.
Q3. What features does the Mobile DVR System include?
Key features typically include:
- Real-time counting
- Data storage and retrieval
- Remote access via mobile devices
- Reporting capabilities
- Integration with other security systems
Q4. Is the system easy to install?
Yes, the system is generally designed for easy installation, often requiring minimal tools and technical expertise.
Q5. Can the system be used outdoors?
It depends on the specific model. Some systems are weatherproof and can be used outdoors, while others are designed for indoor use only.
Q6. How is data from the people counter accessed?
Data can usually be accessed via a mobile app or web interface, allowing users to view real-time statistics and historical data.
Q7. What kind of maintenance is required?
Regular checks to ensure sensors are clean and functioning are recommended, along with software updates as needed.
Q8. Is the data collected secure?
Most systems include encryption and secure access protocols to protect data from unauthorized access.
Q9. Can the system integrate with existing security systems?
Yes, many models can be integrated with other security and surveillance systems for enhanced functionality.
Q10. What is the warranty period for the system?
Warranty periods vary by manufacturer, but they typically range from one to three years.
