4 Channel DVR SD Digital Video Recorder GPS Tracking Devices for automobiles
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW621HD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal; |
| Supply Ability: | 5,000pcs per month; 4 Channel DVR SD Digital Video Recorder GPS Tracking Devices for automobiles |
|
Detail Information |
|||
| Features: | 4G / 3G And GPS Optional, WIFI Auto Download, Basic Monitoring | Power Supply: | 8V-36V |
|---|---|---|---|
| CVBS: | Support | Video Input: | 4 Channels |
| Video Compression: | H.264 / H265 | Storage Capacity: | 2*256G SD Cards |
| Car Cameras: | AHD Up To 2MP 1080P, CVBS D1 | Resolution: | Support 1080P/720P/D1/CIF |
| Gps: | Built-in High Accurate GPS Module(optional) | Applicable: | Bus, Truck, Taxi, Cab, Petrol, Excavator, Mining Truck Fleets |
| High Light: | DVR SD Digital Video Recorder,GPS Tracking 4 Channel DVR |
||
Product Description
4 Channel DVR SD Digital Video Recorder GPS Tracking Devices for automobiles
The 4 channel DVR is specifically designed for use on board mobile vehicles, such as cars, aircraft and boats.
In the CCTV industry, these devices are called MDVR (Mobile Digital Video Recorder) and are actually very different from our standard DVR for analog cameras. In particular, casing, terminals and memory slots are designed to bear strong vibrations and extreme climatic conditions.
These MDVRs are compatible with all analog CVBS or AHD cameras. CVBS is the classic analog video format and is still the most widely used on vehicles, with small monitors.
If you look for the highest resolution, you can choose the AHD format, the high-resolution analog video, that get up to 1MP 720P and 2MP 1080P resolution.
These MDVRs can manage any type of analog camera, both traditional CVBS and AHD, up to 2MP resolution. Obviously the perfect match is with our vehicle cameras, however, if you use the MDVR on a boat or a heavy vehicle, you can connect any camera for traditional AHD systems. If you buy an MDVR model with a network port, you can also connect IP cameras up to 2MP.
SD Digital Video Recorder Features
1) One SD card for storage,max 512G
2) GPS tracking and 4G/5G remote control realtime monitoring optional
3) UPS technology to protect sudden power off
4) The Power and mainboard are integrated with much better quality
5) Mini size and light on weight
Mobile video recorder vehicle Specifications
|
Project
|
Parameter Description
|
|
|
Audio and video input
|
video input
|
AHD input: 4ch 1080P , maximum frame rate 120fps
|
|
audio input
|
2 audio inputs
|
|
|
Audio and video output
|
video output
|
Default 1 CVBS output (VGA output optional)
|
|
voice output
|
1 channel voice output
|
|
|
Audio and video parameter coding
|
video encoding
|
H.264 Main Profile/H.265
|
|
Video resolution
|
1080P/720P/D1 optional
|
|
|
audio coding
|
Default G.726, G.711A optional
|
|
|
storage
|
SD card
|
Support 1 SD card,Max 256GB
|
|
wireless network
|
4G wireless
|
Support 1 SIM card, optional: all mainstream communication modules in the world
|
|
Targeting
|
Beidou/GPS
|
Support hybrid positioning, speed detection, time synchronization
|
|
interface
|
USB
|
1 USB interface, support exporting data
|
|
serial port
|
Support 1 RS232, optional 1 RS485 , external sensor
|
|
|
I/O
|
4 switch inputs, compatible with 1 analog input
|
|
|
network port
|
Optional
|
|
|
Physical Specifications
|
size
|
100 mm (L) * 1 20.8 mm (W) * 32 mm (H) (excluding tail)
|
|
weight
|
Bare metal: 0.6 kg
FCL: 0.8kg (with M 15 Hv -SGNE1-L as standard) |
|
|
working environment
|
Operating temperature
|
-20～+70℃
|
|
Working humidity
|
8%~90% (non-condensing)
|
|
|
other
|
operating mode
|
Remote control, mobile APP, WEB
|
|
Gravity Sensing
|
Built-in GSensor
|
|
|
Configurable AI algorithm
|
Driver identification, people counting, assisted driving, etc.
|
|
Product Details
FQA
1.Q: Does the MDVR support Hard drive and SD card?
A: Yes, HDD version MDVR supports SSD, HDD, and SD card. SD card version MDVR supports max 2 SD card.
The storage capacity can be from 32GB to 2TB.
2.Q: Is it difficult to install MDVR into the vehicle?
A: Actually it is easy to install it into vehicle. Most driver can figure out how to connect the power cables.
And the camera installation is more easy. Just screw, connect and mount on the target place inside the vehicle.
3.Q: If I need door open and close alarm, overspeed alarm, reverse video, brake video, left-turn video, right-turn video, etc,
is it available?
A: Definitely yes!
The I/O RS232 and 485 extension port is for all expanded purposes, including the functions above.
In fact, there are more customized functions which can be connect through this port, such as Fuel sensor, Counter system,
PTZ camera, and so on.
4.Q: We have our own platform and server, can we use your MDVR? Do you have SDK or can you do customized platform for us?
A: Yes, we have SDK ready and welcome your OEM customized order!
