4 Cameras Video 3G Mobile DVR Recorder / Vehicle Camera DVR Support 24 hours recording

4 Cameras Video 3G Mobile DVR Recorder / Vehicle Camera DVR Support 24 hours recording

    • 4 Cameras Video 3G Mobile DVR Recorder / Vehicle Camera DVR Support 24 hours recording
    • 4 Cameras Video 3G Mobile DVR Recorder / Vehicle Camera DVR Support 24 hours recording
    • 4 Cameras Video 3G Mobile DVR Recorder / Vehicle Camera DVR Support 24 hours recording
    • 4 Cameras Video 3G Mobile DVR Recorder / Vehicle Camera DVR Support 24 hours recording
  • 4 Cameras Video 3G Mobile DVR Recorder / Vehicle Camera DVR Support 24 hours recording

    Product Details:

    Place of Origin: Shenzhen,China
    Brand Name: Vanwin Tracking
    Certification: CE/FCC/RoHS
    Model Number: VW605GSW

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pc
    Price: negotiated
    Packaging Details: Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs .
    Delivery Time: 2-3 days for samples,15-30 days for large orders
    Payment Terms: T/T or western Union or Paypal
    Supply Ability: 5,000pcs per month
    Contact Now
    Detailed Product Description
    Power Supply: 8V-36V Storage Capacity: 2.5" Sata Hard Disk+64GB SD Card
    Functions: 3G , GPS Track , Wi-Fi ,G-sensor,6CH Alarm Inpu,Lan Port Software Support: Client,Server,Playback Software
    Applicable: School Bus Or Bus Or Any Vehicle OEM/ODM: YES Or Customize
    USB Port: YES Agents: Negotiable
    3G 4G GPS WIFI: Optional RJ45 Lan Port: Support
    RS232: Support

    4 Cameras Video 3G Mobile DVR Recorder / Vehicle Camera DVR Support 24 hours recording



    3G Mobile DVR is mainly used for vehicle fleeting management with live video and monitoring ,and you can know where the vehicle is with GPS tracking especially necessary for school bus or goods truck or bank money carrying cars. Live monitoring what they are doing.Welcome you.



    Main Features

    1. 4CH, Support 4 cameras
    2.  H.264 compression format
    3. 64GB SD Card
    4. 2.5“ SATA 2TB Hard disk
    5. GPS tracking
    6. 3G remote control
    7. Built-in WIFI for option
    8. 6 alarm input, 1 alarm output
    9. 2 way intercom
    10. Remote oil&power cut-off
    11. Mirror recording in SD card
    12. Patent UPS continuously working to protect data upon sudden power-off
    13. Customized GPS data format sending(optional)
    14. Built-in Heater(optional)
    15. Lockable, metal HDD handle, protect HDD efficiently
    16. Watermark and Time/Date stamp in exported images

    Detailed Specification



    Item

    Description

    OS

    Linux

    Graphics Operation Interface

    System parameters can be set through external display and remote controller

    Security Management

    2-level management for user password, administrator password, supporting encrypted transmission

    Video and Preview

    Video Input, Output

    4-channel video input, 1channel video output; 1.0Vp-p, 75Ω

    OSD

    Character superposition function, information superposition of time and date, device ID and GPS, etc.

    Video Compression Format

    Compression coding. Applying hisilicon hi-performance processor.

    Dual-Stream

    Supported

    Preview Function

    Preview of 1-channel, 4-image stitching, supporting full screen triggered by event and switching of stitched images

    Frame Rate

    PAL: 100 frames/s, up to 25 frames/s per channel; NTSC: 120 frames/s, up to 30 frames/s per channel

    Resolution

    CIF, HD1 and D1 for selection, supporting 2 channels of D1+ 2 channels of CIF at the most

    Quality

    Grade 1 to grade 5 for selection (descending)

    Bit Rate

    CIF: 256Kbps ~ 1.5 Mbps, 8-level bit rates for selection

    HD1: 600Kbps ~ 2 Mbps, 8-level bit rates for selection

    D1: 800Kbps ~ 3Mbps, 8-level bit rates for selection

    Audio

    Audio Input, Output

    4-channel input, 1-channel output

    Compression Format

    G.726 coding

    Recording

    Storage Medium

    Supporting one 2.5” hard drive and one SD card, which supports up to 32G, supporting data redundancy storage technology;

    File Format/ System

    ASF/FAT32

    Video Strategies

    Recording at startup by default, supporting timed recording, recording triggered by alarm and event, as well as manual recording

    Video Search

    Searching by time, type, storage device and other conditions

    Video Playback

    Supporting playback on local device, supporting synchronous playback of up to 4 channels and analysis on vehicle information in the files

    Supporting fast forward, fast backward, play and pause, supporting fast forward and fast backward at 2x, 4x, 8x and 16x speed, supporting file play from selected time

    Alarm

    Alarm Input/ Output

    6-channel on/off signal alarm input, 1-channel on/off signal alarm output

    Alarm Recording

    Prerecording function 15 seconds before alarm, duration of recording after alarm can be adjusted from 30s ~ 30min

    Storage Space Alarm

    Supporting settings for alarm of storage space

    Function Alarm

    GPS overspeed alarm, acceleration alarm, motion detection alarm

    Communication Ports

    RS232, RJ45 10M/100M self-adaptable network interface

    Wireless Transmission (Optional)

    Supporting Wi-Fi;

    GPS (Optional)

    Supporting external GPS

    PTZ Control

    Supporting PTZ control realized by local;

    Parameter Configuration

    Supporting parameter configuration functions for mobile DVR coding channel;

    G-Sensor

    Embedded

    System Upgrading

    Supporting SD card, hard drive upgrading and remote upgrading

    Power Supply and Power Consumption

    Power Supply

    1. ACC on/off

    2. Hard drive lock on/off

    3. Delayed shutdown

    4. Timed on/off

    Input Voltage

    DC:+8V ~ +36V

    Output Voltage

    +12V@4*0.5A; +5V@0.5A

    Power-off Protection

    With patented UPS power supply continuous working technology, it can work for 3~5 seconds after external power supply is cut so that the intactness of video data can be kept upon sudden power failure

    Power Consumption

    <10W in normal operation; <0.5W in standby mode

    Operating Environment

    Temperature

    Normal: 0℃ ~ +60℃; upon hard drive preheating: -25℃ ~ +60℃

    Humidity

    10% to 95%

    Dimensions

    160(W) x62(H) x200(D) mm.

    Weight

    Net: 2200g, Gross: 3500g



    FAQ



    1.About Server:


    1)The server software is free? What are the system requirements to use this software?
    Yes, it is free of charge.
    For server setup, you need to buy a static IP adress from your local network provider, and then the computer should be with good performance (HDD capacity should be above 500GB, Memory above 4G, CPU above 2G, with dual core, Network interface should be 100 Mega or 1000 mega.


    2)What Operating system needs to be used? Windows 7 or 8 or Windows server? Can the WIFI auto download software be placed on the same system?
    RE: yes, you could use windows system, 7 or 8 are both okay. Also the wifi auto download software are with the same system. In fact, our current software are all based on windows system.(only Clients is with android system)



    2.About Clients:
    1)Can we get our own look and feel for the client when we have our own?


    RE:As for the Clients app, we could add your logo or your company name on it if you need, but the others, like menus, functions, structures etc are the same. You could not change the Clients software even you have your own server since the software is developed by our technician, only they could change or decorate.

    2)Is it correct that when we want to connect audio, we can connect a camera less to the system?


    RE:You mean you want to hear the voice when you see the video? If so, no need to connect less camera, you just need to buy a sound pickup to connect together with one or two of the cameras, then the one or two channel will be with audio.



    3)When we start using your server and after some time we build our own, can the IP address in the units be changed remote or do we do this by wire?


    RE: If you build your own server, then you could change the DVR local settings by manual. After you used your own server, then you could run the server TOOl software, then you could remotely change the settings of your vehicles, this is no problem.



    Our CMS Software



    4 Cameras Video 3G Mobile DVR Recorder / Vehicle Camera DVR Support 24 hours recording

    4 Cameras Video 3G Mobile DVR Recorder / Vehicle Camera DVR Support 24 hours recording





    It is designed for all commercial vehicles, especially those that carry passengers. To discover how the the system can be constructed to suit your requirements, contact us for a no obligation consultation.
